1x HDMI 2.0b with HDR port, supports a maximum resolution of 4K 60Hz 1 2; 1x DisplayPort 1.4 port, supports a maximum resolution of 5120x3200 60Hz 1 2; Available only on processors featuring integrated graphics.; Graphics specifications may vary depending on the CPU installed.
Övriga specifikationer
USB
4x USB 3.2 Gen 1 5Gbps ports (2 Type-A ports on the back panel, 2 ports available through the internal USB connectors); 4x USB 2.0 Type-A ports on the back panel; 2x USB 2.0 ports available through the internal USB connector
HDMI
1
Socket
1200
DirectX
12
SATAIII
4
M.2 Slot
1
Mounting
4 mounting holes
PCI-E Gen
Gen4
PCI-E x16
1
Processor
Supports 10th Gen Intel Core Processors, 11th Gen Intel Core Processors, Pentium Gold and Celeron Processors 1; Processor socket LGA1200; Please go to intel.com for compatibility information.
DIMM Slots
2
Dimensions
Priser hos återförsäljare
Butik
Logotyp
Pris
Lager
Inga aktuella priser tillgängliga.
Recensioner
Laddar recensioner…
Mini-ITX Form Factor; 6.7 in. x 6.7 in. (17.0 cm x 17.0 cm)
Box content
MSI does not guarantee the risks or damages caused by changing the cover.; These pictures are for reference only and may vary without notice.
CPU Support
Support for Windows 10 64-bit
DisplayPort
1
Form Factor
Mini-ITX
TPM (header)
1
Expansion Slot
1x PCIe x16 slot Support up to PCIe 4.0 for 11th Gen Intel CPU Support up to PCIe 3.0 for 10th Gen Intel CPU; Support up to PCIe 4.0 for 11th Gen Intel CPU; Support up to PCIe 3.0 for 10th Gen Intel CPU
Memory Channel
Dual
Max Memory (GB)
64
Back panel ports
USB 2.0; DisplayPort; USB 2.0; LAN port; WIFI / Bluetooth; Audio connector; HDMI; USB 3.2 Gen 1 5Gbps Type-A
Operating System
Support for Windows 10 64-bit
WiFi & Bluetooth
Intel Wi-Fi 6 AX201, Bluetooth 5.1
Audio ports (Rear)
Realtek ALC897 Codec
Internal connectors
1x 24-pin ATX main power connector; 1x 8-pin ATX 12V power connector; 4x SATA 6Gb/s connectors; 1x M.2 slots (M-Key); 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports); 1x USB 2.0 connectors (supports additional 2 USB 2.0 ports); 1x 4-pin CPU fan connector; 1x 4-pin water-pump fan connector; 1x 4-pin system fan connectors; 1x Front panel audio connector; 2x System panel connectors; 1x Chassis Intrusion connector; 1x Clear CMOS jumper; 1x TPM module connector
