1x HDMI port, supports a maximum resolution of 4096x2160 @30Hz; 1x DisplayPort, supports a maximum resolution of 4096x2304 @60Hz
Max minneshastighet
2933 MHz
Övriga specifikationer
USB
4x USB 3.2 Gen 1 5Gbps ports (2 Type-A ports on the back panel, 2 ports are available through the internal USB 3.2 Gen 1 5Gbps connector); 4x USB 2.0 ports (2 Type-A ports on the back panel, 2 ports through the internal USB 2.0 connector)
HDMI
1
Socket
1200
DirectX
12
SATAIII
4
M.2 Slot
1
Mounting
4 mounting holes
PCI-E Gen
Gen3
PCI-E x16
1
Processor
Please go to www.intel.com for more compatibility information.; Onboard graphics output are disabled when using F SKU processors.
DIMM Slots
2
Dimensions
Mini-ITX Form Factor; 6.7 in. x 6.7 in. (17.0 cm x 17.0 cm)
Priser hos återförsäljare
Butik
Logotyp
Pris
Lager
Inga aktuella priser tillgängliga.
Recensioner
Laddar recensioner…
Box content
MSI does not guarantee the risks or damages caused by changing the cover.; These pictures are for reference only and may vary without notice.
CPU Support
Support for Windows 10 64-bit
DisplayPort
1
Form Factor
Mini-ITX
TPM (header)
1
Expansion Slot
1x PCIe 3.0 x16 slot (From CPU)
Memory Channel
Dual
Max Memory (GB)
64
Back panel ports
DisplayPort; LAN; Wireless / Bluetooth; Audio Connectors; USB 2.0; HDMI; USB 3.2 Gen 1 5Gbps Type-A; Optical S/PDIF OUT
Operating System
Support for Windows 10 64-bit
WiFi & Bluetooth
Intel Wireless-AC 3168, Bluetooth 4.2
Audio ports (Rear)
5 + Optical S/PDIF
Internal connectors
1x 24-pin ATX main power connector; 1x 8-pin ATX 12V power connector; 4x SATA 6Gb/s connectors; 1x M.2 slot (M-Key); 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports); 1x USB 2.0 connector (supports additional 2 USB 2.0 ports); 1x 4-pin CPU fan connector; 1x 4-pin water-pump fan connector; 1x 4-pin system fan connector; 1x Front panel audio connector; 1x System panel connector; 1x 4-pin RGB LED connector; 1x 3-pin RAINBOW LED connector; 1x Chassis Intrusion connector
