1x HDMI 2.0b with HDR port, supports a maximum resolution of 4K 60Hz12; 1x DisplayPort 1.4 port, supports a maximum resolution of 4K 60Hz12; 1x VGA port, supports the maximum resolutions of 2048x1536 @50Hz, 2048x1280 @60Hz and 1920x1200 @60Hz12; Available only on processors featuring integrated graphics.; Graphics specifications may vary depending on the CPU installed.
Övriga specifikationer
USB
2x USB 3.2 Gen 2 10Gbps Type-A ports on the back panel; 4x USB 3.2 Gen 1 5Gbps ports (2 Type-A ports on the back panel, and 2 ports are available through the internal USB 3.2 Gen 1 5Gbps connector); 2x USB 2.0 Type-A ports on the back panel; 4x USB 2.0 ports are available through the internal USB 2.0 connectors
VGA
1
HDMI
1
Socket
1200
DirectX
12
SATAIII
6
M.2 Slot
2
PCI-E x1
2
PCI-E Gen
Gen4
PCI-E x16
1
DIMM Slots
4
CPU Support
Support for Windows 10 64-bit
Priser hos återförsäljare
Butik
Logotyp
Pris
Lager
Inga aktuella priser tillgängliga.
Recensioner
Laddar recensioner…
DisplayPort
1
Form Factor
MATX
LED Feature
1x 4-pin RGB LED connector; 1x 3-pin RAINBOW LED connector; 4x EZ Debug LED
1x PCIe x16 slot (From CPU) PCI_E1 (From CPU) Support up to PCIe 4.0 for 11th Gen Intel CPU Support up to PCIe 3.0 for 10th Gen Intel CPU; PCI_E1 (From CPU) Support up to PCIe 4.0 for 11th Gen Intel CPU Support up to PCIe 3.0 for 10th Gen Intel CPU; Support up to PCIe 4.0 for 11th Gen Intel CPU; Support up to PCIe 3.0 for 10th Gen Intel CPU; 2x PCIe 3.0 x1 slots (From B560 chpiset)
Memory Channel
Dual
Max Memory (GB)
128
WiFi & Bluetooth
Intel Wi-Fi 6 AX201, Bluetooth 5.1
Audio ports (Rear)
Realtek ALC897 Codec
Internal connectors
1x 24-pin ATX main power connector; 1x 8-pin ATX 12V power connector; 6x SATA 6Gb/s connectors; 2x M.2 slots (M-Key); 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB Gen 1 ports); 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports); 1x 4-pin CPU fan connector; 1x 4-pin water-pump fan connector; 2x 4-pin system fan connectors; 1x Front panel audio connector; 2x System panel connectors; 1x Chassis Intrusion connector; 1x Clear CMOS jumper; 1x TPM module connector; 1x Serial port connector; 1x Tuning Controller Connector
Serial ports(Front)
1
USB 2.0 ports (Rear)
2
USB 3.2 ports (Rear)
2(Gen 2, Type A), 2(Gen 1, Type A)
Back panel Connectors
Keyboard / Mouse; VGA; DisplayPort; USB 3.2 Gen 2 10Gbps Type-A; LAN port; WiFi / Bluetooth; Audio connector; USB 2.0; HDMI; USB 3.2 Gen 1 5Gbps Type-A
