MS128GP

Fläktlös

Nej

Ethernet

1 Gbps

MAC-tabell

8 K

PoE-portar

802

Portar

28

Strömförbrukning

350.14 W

Växlingskapacitet

56 Gbps

Överföringsmetod

Store and Forward

Övriga specifikationer

LED

• Power / • Link/Act / • PoE Status / • PoE Max

PoE Ports

• Standard: compatible with 802.3af/at PDs / • PoE Ports: Ports 1–24, up to 30 W per port / • PoE Power Budget: 295 W

Dimensions

17.3 x 7.1 x 1.7 in (440 x 180 x 44 mm)

Environment

• Operating Temperature: -10°C to 45°C (14°F to 113°F) / • Storage Temperature: -40°C to 70°C (-40°F to 158°F) / • Operating Humidity: 10% to 90% RH, non-condensing / • Storage Humidity: 5% to 90% RH, non-condensing

Certifications

CE, RoHS

Package Contents

• MS128GP / • Power Cord / • Installation Guide / • Mounting Brackets and Fittings

Advanced Features

• Compatible With IEEE 802.3at/af Compliant PDs / • Extend Mode (Up to 250m PoE power supply and data transmission) / • Priority Mode (Ports 1-4) / • Isolation Mode (Ports 1-12, 13-24) / • PoE Auto Recovery (Ports 1-24) / • MAC Address Auto-Learning And Auto-Aging / • IEEE802.3x Flow Control

Transmission Medium

• 10BASE-T: 2-pair UTP/STP of Cat. 3 or above (≤100 m) / • 100BASE-TX: 2-pair UTP/STP of Cat. 5 or above (≤100 m) / • 1000BASE-T: 4-pair UTP/STP of Cat. 5e or above (≤100 m) / • 1000BASE-X: MMF, SMF

Max Heat Dissipation

• 1193.98 BTU/hr (110V/60 Hz @ 25 °C, with 295 W PD connected) / • 1147.74 BTU/hr (220V/50 Hz @ 25 °C, with 295 W PD connected)

Physical Security Lock

Yes

Standards and Protocols

IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3z, IEEE 802.3af, IEEE 802.3at
