WiFi

WiFi 5

5 GHz

Ja

6 GHz

Nej

Ethernet

100 Mbps

WAN-portar

3

2,4 GHz

Ja

Övriga specifikationer

LED

1x SYS / 1x Turbo / 3x LAN / 1x WAN

QoS

Time Settings / Priority Control

DDNS

NO-IP / DynDNS

DHCP

Address Reservation / DHCP Client List / Server

IPTV

IGMP Proxy / IGMP Snooping / Bridge / Tag VLAN

Power

Input：100~240V, 50/60Hz / Output: 12V/1A

Button

1x WPS Button / 1x Reset Button / 1x Turbo Button

System

Firmware Upgrade / Backup and Restore / Administration / System Log / Time & Language Settings / Reboot

Antenna

2x 5G External Antennas(7dBi) / 2x 2.4G External Antennas(7dBi)

Language

English / Spanish - Mexico / Portuguese - Brazil / Russian

Security

SPI Firewall / Access Control / IP & MAC Binding

WAN Mode

Dynamic IP / Static IP / PPPoE / PPTP / L2TP

Protocols

IPv4 / IPv6

Dimensions

215.80x140.33x50.45mm

Diagnostics

Ping / Traceroute

Environment

• Operating Temperature: 0°C~40°C (32°F~104°F) / • Operating Humidity: 10%~90% Non-Condensing / • Storage Humidity: 5%~90% Non-Condensing

ISP Feature

ISP Preset(Agile Config)

Wi-Fi Class

AC1200

Installation

Desktop / Wall-mount

Guest Network

2.4G Guest Network / 5G Guest Network

Wi-Fi (5 GHz)

867Mbps

LED Management

LED Control / Night Mode

NAT Forwarding

Port Forwarding / Port Triggering / DMZ / UPnP

Operation Mode

Router/AP/Range Extender

Wi-Fi (2.4 GHz)

300Mbps

Carton Dimension

595x420x330mm

Package Contents

• AC1200 Wi-Fi 5 Router MR39-HP / • Power Adapter / • Quick Installation Guide / • RJ45 Ethernet Cable

Units per Carton

10

Advanced Features

Beamforming

Device Management

MERCUSYS APP / Webpage

Max Channel Width

80MHz

Parental Controls

Profile Settings / Time Control / Pause the Internet / Website Filtering

Wireless Security

WPA/WPA2/WPA3

Wireless Functions

Guest Network / Wireless Schedule / WPS / AP Isolation

Max Wi-Fi Modulation

1024 QAM

Reception Sensitivity

5G: / 11ac VHT20 MCS0:-96dBm / 11ac VHT20 MCS8:-74dBm / 11ac VHT40 MCS9:-69dBm / 11ac VHT80 MCS9:-65dBm / 2.4G / 11g 6Mbps: -96dBm / 11g 54Mbps: -78dBm / 11n HT40 MCS7:-74dBm / 11n HT20 MCS7:-77dBm

Retail Package Weight

773g

Retail Package Dimension

413x295x65mm
