Typ

SATA SSD

Marknad

Consumer

Kapacitet

480 GB

NAND-typ

TLC

DRAM-cache

Yes

Gränssnitt

SATA Rev. 3.0 (6Gb/s) – with backwards compatibility to SATA Rev. 2.0 (3Gb/s)

Formfaktor

2.5 inch

Övriga specifikationer

MTBF

2 million hours

UBER

≤10 -17

Weight

92.34g

Dimensions

69.9mm x 100mm x 7mm

Endurance (TBW)

480GB – 876TBW, 1 DWPD (5 years), 1.66 DWPD (3 years) 960GB – 1752TBW, 1 DWPD (5 years), 1.66 DWPD (3 years) 1.92TB – 3504TBW, 1 DWPD (5 years), 1.66 DWPD (3 years) 3.84TB – 7008TBW, 1 DWPD (5 years), 1.66 DWPD (3 years) 7.68TB – 14016TBW, 1 DWPD (5 years), 1.66 DWPD (3 years)

Hot-plug capable

Static and dynamic wear levelling

Variant Capacity

480GB

Warranty/support

Limited 5-year warranty with free technical support

Power consumption

Idle: 1.30W Average: 1.45W Max read: 1.6W Max write: 3.6W

Storage temperature

-40℃ ~ 85℃

Vibration operating

2.17G Peak (7–800Hz)

Operating temperature

0℃ ~ 70℃

Enterprise SMART tools

Reliability tracking, usage statistics, life remaining, wear levelling, temperature

Vibration non-operating

20G peak (10–2000Hz)

Variant Security Features

None

Typical latency - read/write

<200 µs / <30 us,,

Steady-state 4k random read/write

480GB – 94,000/41,000 IOPS 960GB – 94,000/65,000 IOPS 1.92TB – 94,000/78,000 IOPS 3.84TB – 94,000/59,000 IOPS 7.68TB – 94,000/34,000 IOPS

Hardware-based power loss protection

Yes

Quality of service (latency),,(99.999)

Read/Write 480GB – 180/110 uSec 960GB – 3.84TB – 200/300 uSec 7.68TB – 240/170 uSec
