Z20 Black

Djup

370 mm

Bredd

186 mm

Höjd

295 mm

Volym

20.3 L

Vikt

5 kg

Front I/O

USB 3.x Type-C x 1, USB 3.x Type-A x 1, Audio combo x 1

Chassityp

Mini Tower

Material

Metal, Glass

Dimensioner

370 mm 186 mm 295 mm(depth/width/height)

Formfaktor

Mini-ITX, Micro-ATX

Max 120 mm-fläktar

5

Max 140 mm-fläktar

4

2.5"-fack

3

3.5"-fack

1

Max GPU-längd

363 mm

Max PSU-längd

180 mm

Sidopanel

Tempered Glass

Expansionsplatser

4

Max kylarhöjd

164 mm

Radiatorstöd (topp)

240mm

Övriga specifikationer

Top

2 x 120mm / 2 x 140mm

2.5"

up to 3,depends on other hardware configurations

3.5"

up to 1,depends on other hardware configurations

Rear

1 x 120mm / 1 x 92mm

Bottom

2 x 120mm / 2 x 140mm,depends on other hardware configurations

Model Name

Z20 Black V1.0

DRIVE BAYS 2.5"

up to 3,depends on other hardware configurations

DRIVE BAYS 3.5"

up to 1,depends on other hardware configurations

FAN SUPPORT Top

2 x 120mm / 2 x 140mm

SFX PSU Support

SFX / SFX-L

FAN SUPPORT Rear

1 x 120mm / 1 x 92mm

KEY SPECS Weight

N.W. 5kg / G.W. 6.5kg

FAN SUPPORT Bottom

2 x 120mm / 2 x 140mm,depends on other hardware configurations

Headset Audio Jack

1

USB 3.2 Gen 1 Type-A

1

USB 3.2 Gen 2 Type-C

1

MODEL NAME Model Name

Z20 Black V1.0

KEY SPECS Case Material

SPCC Steel, Tempered Glass

KEY SPECS Expansion Slots

4

KEY SPECS Motherboard Support

Mini-ITX / Micro-ATX

FRONT I/O PORTS Headset Audio Jack

1

FRONT I/O PORTS USB 3.2 Gen 1 Type-A

1

FRONT I/O PORTS USB 3.2 Gen 2 Type-C

1

COMPATIBILITY & CLEARANCE GPU Clearance

Up to 363mm, depends on other hardware configurations (Refer to page 11)

COMPATIBILITY & CLEARANCE SFX PSU Support

SFX / SFX-L

COMPATIBILITY & CLEARANCE Radiator Clearance

Top，up to 240mm

COMPATIBILITY & CLEARANCE ATX PS2 PSU Clearance

Up to 180mm, recommended length ≤140mm,depends on other hardware configurations (Refer to page 11)

COMPATIBILITY & CLEARANCE CPU Air Cooler Clearance

164mm MAX（Intel CPU）or 163mm MAX（AMD CPU）

DIMENSIONS(with handle/feet and other protrusions)

382mm x 198mm x 335mm(depth/width/height)

KEY SPECS DIMENSIONS(w/o handle/feet and other protrusions)

370mm x 186mm x 295mm(depth/width/height)

KEY SPECS DIMENSIONS(with handle/feet and other protrusions)

382mm x 198mm x 335mm(depth/width/height)
