HA-600AA2-Rev

Effekt

600 W

Effektivitet

80 PLUS

Skydd

Overload protection Overvoltage protection Overcurrent protection Short-circuit protection No Load Protection | + + + + +

Övriga specifikationer

Input

Input voltage Frequency Power consumption | AC 200 - 240 V~ 50 Hz 8A @230V

Output

Output voltage + 3.3V | + 5V | + 12V | - 12V | + 5Vsb Total rated power Rated power 3.3V + 5V Voltage tolerance Ripple/ Noise | Rated current max. 20A | max. 20A | max. 50A | max. 0.3A | max. 2.5A max. 600W max. 100W +/- 3% <50mV @ +3.3V, +5V, +5Vsb | <100mV @ +12V | <120mV @ -12V

Safety

Overload protection Overvoltage protection Overcurrent protection Short-circuit protection No Load Protection | + + + + +

Features

600Watt power supply | 80PLUS EU Gold | Counter-rotating 80mm fan | Numerous connections for mainboard, drives and peripherals

Warranty

2 years

Logistic data

Dimension Net weight Gross weight Article number GTIN Packing unit | 150 x 160 x 86 mm 1.725 kg 2.110 kg 88882247 4260455649896 1 pcs | 5 pcs (carton)

Scope of delivery

Power supply | Power cord | Screws | Cable ties | Manual

Economic data: @ 20% load

90.01 %

Economic data: @ 50% load

92.26 %
