ECC

No

Hastighet

1066 MHz

Moduler

1

Spänning

1.35 V

Kapacitet

8 GB

Formfaktor

SO-DIMM

Minnestyp

DDR3

Kapacitet per modul

8 GB

Övriga specifikationer

Model Name

DDR3 SODIMM

PCB Height

1.18 Inches

Pin Number

204pin

Description

DDR3 SODIMM is a compact, JEDEC-compliant memory for embedded, surveillance, and automation. Available in 1GB, 2GB, 4GB, and 8GB with speeds of 1066, 1333, 1600 and 1866 MT/s.

M3S0-1GMWFCQE

128M x 16 1R x 16 0°C ~ 85°C DDR3 1866 1GB SODIMM

M3S0-1GMWFLQE

128M x 16 1R x 16 0°C ~ 85°C DDR3L 1866 1GB SODIMM

M3S0-2GMJCCQE

256M x 8 1R x 8 0°C ~ 85°C DDR3 1866 2GB SODIMM

M3S0-2GMJCLQE

256M x 8 1R x 8 0°C ~ 85°C DDR3L 1866 2GB SODIMM

M3S0-2GMVFCQE

256M x 16 1R x 8 0°C ~ 85°C DDR3 1866 2GB SODIMM

M3S0-2GMVFLQE

256M x 16 1R x 8 0°C ~ 85°C DDR3L 1866 2GB SODIMM

M3S0-4GMJDCQE

256M x 8 2R x 8 0°C ~ 85°C DDR3 1866 4GB SODIMM

M3S0-4GMJDLQE

256M x 8 2R x 8 0°C ~ 85°C DDR3L 1866 4GB SODIMM

M3S0-4GMSCCQE

512M x 8 1R x 16 0°C ~ 85°C DDR3 1866 4GB SODIMM

M3S0-4GMSCLQE

512M x 8 1Rx 8 0°C ~ 85°C DDR3L 1866 4GB SODIMM

M3S0-4GMV0CQE

256M x 16 2R x 16 0°C ~ 85°C DDR3 1866 4GB SODIMM

M3S0-4GMV0LQE

256M x 16 2R x 8 0°C ~ 85°C DDR3L 1866 4GB SODIMM

M3S0-8GMSDCQE

512M x 8 2R x 16 0°C ~ 85°C DDR3 1866 8GB SODIMM

M3S0-8GMSDLQE

512M x 8 2R x 8 0°C ~ 85°C DDR3L 1866 8GB SODIMM

Thermal Shock

-40°C ~ 110°C, 500 Cycles

Package Drop Test

Drop Height 76 cm, ISTA-1A

Operating Temperature

0°C ~ 85°C

DRAM Module Insert & Extract Test

100 Cycles, EIA-364-9
