Max minne

8 GB

PCIe-platser

1 x M.2 Socket 1 connector for the wireless communication module (M2_WIFI) 1 x full size Mini PCIe slot (MSATA_MPCIE) * The MSATA_MPCIE slot can also be used as an MSATA connector.

SATA-portar

1

Ljudkodek

Realtek ALC887codec

Dimensioner

100 × 72mm

Minnestyp

DDR3

Minnesplatser

1

Displayutgångar

Integrated in the SoC: 1 x HDMI port, supporting a maximum resolution of 3840x2160@30 Hz Maximum shared memory of 512 MB

Max minneshastighet

1600 MHz

Övriga specifikationer

USB

Integrated in the SoC: 2 x USB 3.0/2.0 ports on the back panel 2 x USB 2.0/1.1 ports available through the internal USB headers

BIOS

1 x 128 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Anmärkningar

Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website.Most hardware/software vendors may no longer offer drivers to support Win9X/ME/2000/XP SP1/SP2. If drivers are available from the vendors, we will update them on the GIGABYTE website.

I/O kontroller

iTE I/O Controller Chip

Operativsystem

Support for Windows 10 64-bit

Unika funktioner

Support for Xpress Install Support for @BIOS Support for APP Center * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications

Hårdvaru visning

Voltage detection Temperature detection

Bundlad programvara

Norton Internet Security (OEM version)

Interna I/O kontakter

1 x SATA 6Gb/s connector 1 x SATA power connector 1 x front panel header 1 x flat panel display header 1 x front panel audio header 1 x USB 2.0/1.1 header 1 x serial port header 1 x serial port power select jumper (COM_PW) 1 x LCDVCC/MON header (LCDVCC_MON) 1 x LVDS header 1 x GPIO header 1 x SMBUS 1 x Battery Cable header

Kontakter på baksidan

1 x DC In power jack 1 x HDMI port 2 x USB 3.0/2.0 ports 1 x RJ-45 port
