Sockel

LGA 1200

Chipset

Intel H410 Express Chipset

M.2-platser

1

Max minne

64 GB

PCIe-platser

1 x PCI Express x16 slot, running at x16 2 x PCI Express x1 slots (All of the PCI Express slots conform to PCI Express 3.0 standard.) 1 x PCI slot 1 x M.2 Socket 1 connector for the wireless communication module (M2_E)

SATA-portar

4

Ljudkodek

Realtek ALC887

Dimensioner

244 × 244mm

Minnestyp

DDR4

Minnesplatser

2

Displayutgångar

Integrated Graphics Processor-Intel HD Graphics support: 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz 1 x HDMI port, supporting a maximum resolution of 3840 x 2160@30Hz * Support for HDMI 2.0 version, HDCP 2.2, and HDR. 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz 1 x Dual channel LVDS co-lay with eDP (Default is LVDS) * Support for DisplayPort 1.2 version, HDCP 2.2, and HDR. Support for up to 2 displays at the same time Maximum shared memory of 512 MB

Max minneshastighet

2133 MHz

Övriga specifikationer

TPM

Infineon chip, supporting TPM 2.0 (Optional)

USB

Chipset: 4 x USB 3.0/2.0 ports on the back panel 4 x USB 2.0/1.1 ports available through the internal USB headers

BIOS

1 x 128 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Anmärkningar

Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website.Most hardware/software vendors may no longer offer drivers to support Win9X/ME/2000/XP. If drivers are available from the vendors, we will update them on the GIGABYTE website.

I/O kontroller

ＮuvoTon NCT6116D

Operativsystem

Support for Windows 10 64-bit /Linux

Unika funktioner

Support for @BIOS Support for Q-Flash

Hårdvaru visning

Voltage detection Temperature detection Fan speed detection Overheating warning Fan fail warning Fan speed control * Whether the fan speed control function is supported will depend on the cooler you install.

Bundlad programvara

Norton Internet Security (OEM version)

Interna I/O kontakter

1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 1 x system fan header 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 2 x USB 2.0/1.1 header 6 x serial port power select jumpers 1 x GPIO header(LPT) 1 x LVDS header 1 x LVDS drive voltage jumper (LCD_VCC) 1 x backlight switch header (BL_SW) 1 x flat panel display switch header (MON_SW) 1 x flat panel display header (FPD) 1 x speaker header (SPKR) 1 x buzzer header (SPEAKER) 1 x Clear CMOS jumper 1 x chassis intrusion header 1 x I2C jumper 1 x SMBUS jumper

Operating Temperature

0°C to +60°C

Kontakter på baksidan

4 x USB 3.0/2.0 ports 2 x RJ-45 ports 1 x D-Sub port 1x HDMI1.4 port (Note) 1 x DisplayPort 1 x audio jacks(line in/line out/Mic-in)
