Vikt

6.16 kg

Material

Steel, Tempered Glass

Dimensioner

395 × 212 × 440 mm

Formfaktor

ATX, mATX, ITX

Medföljande fläktar

front: 1x Dynamic X2 GP-12; rear: 1x Dynamic X2 GP-12

Max GPU-längd

315 mm

Max PSU-längd

175 mm

Sidopanel

Tempered Glass

Expansionsplatser

7

Max kylarhöjd

170 mm

Radiatorstöd (topp)

120mm / 240mm

Radiatorstöd (front)

120mm / 240mm / 360mm / 140mm / 280mm

Övriga specifikationer

EAN

Black Solid: 7340172700081, Black TG Dark : 7350041084891, Black TG Clear : 7350041084891, White TG Clear: 7340172700104

UPC

Black Solid: 84327610081, Black TG Dark: 817301014892, Black TG Clear: 84327610074

Volume

36.5 liters

Top fan

2x 120/140 mm

Rear fan

1x 120 mm (1x Dynamic X2 GP-12 included)

Warranty

2 Years

Front fan

3x 120 mm or 2x 140 mm (1x Dynamic X2 GP-12 included)

Other EAN

Black Solid: 7340172700081, Black TG Dark : 7350041084891, Black TG Clear : 7350041084891, White TG Clear: 7340172700104

Other UPC

Black Solid: 84327610081, Black TG Dark: 817301014892, Black TG Clear: 84327610074

Bottom fan

1x 120 mm

Net weight

Solid: 6.16 kg, TG: 6.45 kg

Front ports

2x USB 3.0, Audio I/O, Power button, Reset button

Dust filters

Bottom fan + PSU, Front fans, Top fans

Product code

Black Solid: FD-CA-MESH-C-BKO, Black TG Dark : FD-CA-MESH-C-BKO-TG, Black TG Clear: FD-CA-MESH-C-BKO-TGL, White TG Clear: FD-CA-MESH-C-WT-TGC

Top radiator

120/240 mm (max component height on motherboard 40 mm)

Rear radiator

120 mm (max width 125 mm)

Front radiator

120/240/360 mm, 140/280 mm

GPU max length

315 mm with front fan mounted

Other Warranty

2 Years

PSU max length

175 mm

Package weight

Solid: 7.52 kg, TG: 7.81 kg

Expansion slots

7

Left side panel

Steel

Package contents

Meshify C computer case, User manual, Accessory box, Top filter

Right side panel

Steel

Total fan mounts

7

Dimensions Volume

36.5 liters

Power supply type

ATX

Other Product code

Black Solid: FD-CA-MESH-C-BKO, Black TG Dark : FD-CA-MESH-C-BKO-TG, Black TG Clear: FD-CA-MESH-C-BKO-TGL, White TG Clear: FD-CA-MESH-C-WT-TGC

Cable routing space

15-35 mm

Captive thumbscrews

Both side panels, SSD brackets

Fixed velcro straps

Yes

CPU cooler max height

170 mm

Cable routing grommets

Yes

Other Package contents

Meshify C computer case, User manual, Accessory box, Top filter

Specifications Top fan

2x 120/140 mm

Case dimensions (LxWxH)

395 x 212 x 440 mm

Dimensions Package weight

Solid: 7.52 kg, TG: 7.81 kg

Motherboard compatibility

ATX, mATX, ITX

Specifications Bottom fan

1x 120 mm

Package dimensions (LxWxH)

542 x 298 x 493 mm

Specifications Front ports

2x USB 3.0, Audio I/O, Power button, Reset button

3.5" or 2.5" Drive capacity

2

Compatibility Rear radiator

120 mm (max width 125 mm)

Specifications Dust filters

Bottom fan + PSU, Front fans, Top fans

Dedicated 2.5" drive capacity

3

Compatibility Power supply type

ATX

Compatibility Cable routing space

15-35 mm

Specifications Captive thumbscrews

Both side panels, SSD brackets

Specifications Fixed velcro straps

Yes

Dimensions Package dimensions (LxWxH)

542 x 298 x 493 mm

Specifications Cable routing grommets

Yes

Specifications 3.5" or 2.5" Drive capacity

2

Specifications Dedicated 2.5" drive capacity

3

Case dimensions - with feet/protrusions/screws

413 x 217 x 453 mm

Dimensions Case dimensions - with feet/protrusions/screws

413 x 217 x 453 mm
