Fläktstorlek

15 mm

Modulär

Full

Effekt

650 W

Garanti

10 years

Dimensioner

125 × 125 × 63.5 mm

Effektivitet

Gold

Formfaktor

SFX-L

Skydd

Over voltage protection - Under voltage protection - Over power protection - Short circuit protection - Over current protection - Over temperature protection

EPS-kontakter

1

SATA-kontakter

8

PCIe 8-pin-kontakter

4

Övriga specifikationer

5V

20A

ATX

1

EAN

7340172702023

UPC

843276102029

3.3V

20A

PCIe

4

*NOTE

Ion SFX-L is not compatible with Node 202

+5Vsb

3A

Fan type

Slim (15 mm) FDB bearing 120 mm fan

Warranty

10 Years

Other EAN

7340172702023

Other UPC

843276102029

PSU Color

Black/Gunmetal

ATX 24-pin

350

Cable type

Modular 24-pin: Braided sleeve UltraFlex wire - Others: Flat UltraFlex wire

Capacitors

105°C Japanese Polymer

EPS/ATX12V

1

Cable Color

Black

Total Power

650W

DC Output 5V

20A

PCIe 6+2 pin

400+100 x2

Product code

FD-PSU-ION-SFX-650G-BK

DC Output 12V

54A

Input current

8A/4A (650G)

Input voltage

100-240V AC

Connectors ATX

1

DC Output -12V

0.3A

DC Output 3.3V

20A

Modular cables

Fully modular

Package weight

2.07 kg

DC Output +5Vsb

3A

Input frequency

50-60 Hz

PSU form factor

SFX-L*

Package contents

• Ion SFX-L PSU with protective bag • Modular cables in a convenient storage bag • Screw pack with Velcro cable ties • SFX-to-ATX bracket • AC power cord (localized) • User manual

EPS/ATX12V 4+4 pin

400

Other Product code

FD-PSU-ION-SFX-650G-BK

Standby efficiency

ErP 2013 (<0.45W @230 VAC, 45 mA load on +5Vsb)

Number of 12V rails

1

Protection features

Over voltage protection - Under voltage protection - Over power protection - Short circuit protection - Over current protection - Over temperature protection

3.3V and 5V combined

100W

Other Package weight

2.07 kg

Specifications *NOTE

Ion SFX-L is not compatible with Node 202

Connectors Peripheral

2

80PLUS® Certification

Gold

Net weight (unit only)

1.15 kg

Other Package contents

• Ion SFX-L PSU with protective bag • Modular cables in a convenient storage bag • Screw pack with Velcro cable ties • SFX-to-ATX bracket • AC power cord (localized) • User manual

Semi-passive operation

Yes (Zero RPM)

Sleep State Compliance

C6/C7

Unit dimensions (LxWxH)

125 x 125 x 63.5 mm

Specifications PSU Color

Black/Gunmetal

Specifications Cable type

Modular 24-pin: Braided sleeve UltraFlex wire - Others: Flat UltraFlex wire

Specifications Capacitors

105°C Japanese Polymer

Approvals & Certifications

CE, FCC, TUV, cTUVus, EAC, RCM, CCC, BSMI, CB, RoHS, WEEE

Package dimensions (LxWxH)

260 x 170 x 95 mm

Specifications Cable Color

Black

Other Net weight (unit only)

1.15 kg

Specifications Input current

8A/4A (650G)

Specifications Input voltage

100-240V AC

DC Output 3.3V and 5V combined

100W

Specifications Input frequency

50-60 Hz

Other Package dimensions (LxWxH)

260 x 170 x 95 mm

Specifications Standby efficiency

ErP 2013 (<0.45W @230 VAC, 45 mA load on +5Vsb)

Specifications Number of 12V rails

1

Specifications Semi-passive operation

Yes (Zero RPM)

Specifications Sleep State Compliance

C6/C7

Life expectancy (MTBF) at max output load

100,000 hours

Maximum operating temperature (full load)

40°C - Maximum 80% load at 50°C

Specifications Approvals & Certifications

CE, FCC, TUV, cTUVus, EAC, RCM, CCC, BSMI, CB, RoHS, WEEE

Specifications Life expectancy (MTBF) at max output load

100,000 hours

Specifications Maximum operating temperature (full load)

40°C - Maximum 80% load at 50°C

Cable Configuration (length in mm between connectors) SATA

300+200+200+100 x2

Cable Configuration (length in mm between connectors) ATX 24-pin

350

Cable Configuration (length in mm between connectors) Peripheral

300+200

Cable Configuration (length in mm between connectors) PCIe 6+2 pin

400+100 x2

Cable Configuration (length in mm between connectors) EPS/ATX12V 4+4 pin

400
