Fläktstorlek

140 mm

Modulär

Full

Effekt

860 W

Garanti

10 years

ATX-version

ATX 2.4

Formfaktor

ATX

Skydd

Over voltage protection. Under voltage protection. Over power protection. Short circuit protection. Over current protection. Over temperature protection

SATA-kontakter

10

Övriga specifikationer

5 V

22 A

EAN

7340172701927

UPC

843276101923

3.3 V

22 A

Fan type

Customized 140 mm FDB bearing Fractal Design Dynamic Series fan

Warranty

10 years

Other EAN

7340172701927

Other UPC

843276101923

Cable type

Modular 24-pin: Braided sleeve UltraFlex wire. Others: Flat UltraFlex wire

Capacitors

Japanese

Total Power

860 W

EPS12V 8-pin

600 mm

Product code

FD-PSU-IONP-860P-BK

DC output 5 V

22 A

Input current

10A/5A

Input voltage

100-240V AC

ATX12V 4+4 pin

700 mm

DC output 12 V

71.6 A

Modular cables

Fully modular

Package weight

2.975 kg

DC output -12 V

0.3 A

DC output 3.3 V

22 A

Input frequency

50-60 Hz

Package content

Ion+ PSU with protective bag, Modular cables in a convenient storage bag, Screw pack with Velcro cable ties, AC power cord (localized), User manual

Unit measurements

150 x 150 x 86 mm

Other Product code

FD-PSU-IONP-860P-BK

Standby efficiency

ErP 2013 (<0.45W @230. VAC, 45 mA load on +5Vsb)

Number of 12V rails

1

Protection features

Over voltage protection. Under voltage protection. Over power protection. Short circuit protection. Over current protection. Over temperature protection

5 V Standby (+5 Vsb)

3 A

Other Package weight

2.975 kg

Connectors ATX 24-pin

1

Connectors Peripheral

4

Other Package content

Ion+ PSU with protective bag, Modular cables in a convenient storage bag, Screw pack with Velcro cable ties, AC power cord (localized), User manual

3.3 V and 5 V combined

120 W

Semi-passive operation

Yes, user selectable (Zero RPM)

Sleep State Compliance

C6/C7

80 PLUS® Certification

Platinum

Connectors PCIe 6+2 pin

6

Unit weight (unit only)

1.665 kg

Specifications Cable type

Modular 24-pin: Braided sleeve UltraFlex wire. Others: Flat UltraFlex wire

Specifications Capacitors

Japanese

Approvals & Certifications

CE, FCC, TUV, cTUVus, EAC, RCM, CCC, BSMI, CB, RoHS, WEEE

PSU specification compliance

ATX12V 2.4 / EPS12V 2.92

Specifications Input current

10A/5A

Specifications Input voltage

100-240V AC

ATX12V 4+4 pin / EPS12V 8-pin

2

DC output 5 V Standby (+5 Vsb)

3 A

Package dimensions (W x H x D)

325 x 110 x 210 mm

Specifications Input frequency

50-60 Hz

DC output 3.3 V and 5 V combined

120 W

Specifications Unit measurements

150 x 150 x 86 mm

Specifications Standby efficiency

ErP 2013 (<0.45W @230. VAC, 45 mA load on +5Vsb)

Specifications Number of 12V rails

1

Other Package dimensions (W x H x D)

325 x 110 x 210 mm

Specifications Semi-passive operation

Yes, user selectable (Zero RPM)

Specifications Sleep State Compliance

C6/C7

Specifications 80 PLUS® Certification

Platinum

Specifications Unit weight (unit only)

1.665 kg

Connectors ATX12V 4+4 pin / EPS12V 8-pin

2

Life expectancy (MTBF) at max output load

100,000 hours

Specifications Approvals & Certifications

CE, FCC, TUV, cTUVus, EAC, RCM, CCC, BSMI, CB, RoHS, WEEE

Maximum operating temperature at full load

50°C

Cable configuration (length between connectors) SATA

400+120+120+120 mm & 650+120 mm

Specifications Life expectancy (MTBF) at max output load

100,000 hours

Specifications Maximum operating temperature at full load

50°C

Cable configuration (length between connectors) ATX 24-pin

600 mm

Cable configuration (length between connectors) Peripheral

400+120+120+120

Cable configuration (length between connectors) EPS12V 8-pin

600 mm

Cable configuration (length between connectors) PCIe 6+2 pin

550+120 mm x2

Cable configuration (length between connectors) ATX12V 4+4 pin

700 mm
