Fläktstorlek

140 mm

Modulär

Full

Effekt

560 W

Garanti

10 years

ATX-version

ATX 2.52

Dimensioner

150 × 150 × 86 mm

Effektivitet

Platinum

Formfaktor

ATX

Skydd

Over voltage protection, Under voltage protection, Overpower protection, Short circuit protection, Over current protection, Over temperature protection

SATA-kontakter

6

Övriga specifikationer

5V

20A

EAN

7340172702856

JAN

4537694282703

UPC

843276102852

3.3V

20A

+5Vsb

3A

Fan type

140 mm FDB bearing Fractal Design Dynamic series fan

Warranty

10 Years

Other EAN

7340172702856

Other JAN

4537694282703

Other UPC

843276102852

ATX 24-pin

1

Cable type

Modular 24-pin cable: Black UltraFlex wires in braided sleeve Other modular cables: Flat black UltraFlex wires

Capacitors

Japanese

Total Power

560W

ATX 20+4 pin

600 mm

DC Output 5V

20A

EPS12V 8-pin

600 mm

Product code

FD-P-IA2P-560

DC Output 12V

46.6A

Input current

10A/5A

Input voltage

100-240V C

DC Output -12V

0.3A

DC Output 3.3V

20A

Modular cables

Fully modular

Package weight

2.76 kg

ATX 12V 4+4 pin

700 mm

DC Output +5Vsb

3A

Input frequency

50-60 Hz

Life expectancy

100,000 hours

Package contents

Power Supply, Power Supply storage bag, Modular cable kit in storage bag, User guide, AC Power cord, Velcro cable ties and mounting screw pack, Included in packaging is a red note as well

Other Product code

FD-P-IA2P-560

Standby efficiency

ErP 2013 (<0.45W @230. VAC, 45 mA load on +5Vsb)

Protection features

Over voltage protection, Under voltage protection, Overpower protection, Short circuit protection, Over current protection, Over temperature protection

3.3V and 5V combined

110W

Other Package weight

2.76 kg

Connectors ATX 24-pin

1

Connectors Peripheral

4

80PLUS® certification

Platinum

Net weight (unit only)

2.24 kg

Other Package contents

Power Supply, Power Supply storage bag, Modular cable kit in storage bag, User guide, AC Power cord, Velcro cable ties and mounting screw pack, Included in packaging is a red note as well

Semi-passive operation

Yes, user selectable (Zero RPM)

Sleep state compliance

C6/C7

Connectors PCIe 6+2 pin

4

Unit dimensions (LxWxH)

150 x 150 x 86 mm

Specifications Cable type

Modular 24-pin cable: Black UltraFlex wires in braided sleeve Other modular cables: Flat black UltraFlex wires

Specifications Capacitors

Japanese

Approvals & certifications

CE, FCC, TUV, cTUVus, EAC, RCM, CCC, BSMI, CB, KC+KCC

Package dimensions (LxWxH)

325 x 210 x 110 mm

Other Net weight (unit only)

2.24 kg

PSU specification compliance

ATX12V 2.52; EPS12V 2.92

Specifications Input current

10A/5A

Specifications Input voltage

100-240V C

ATX12V 4+4 pin / EPS12V 8-pin

2

DC Output 3.3V and 5V combined

110W

Specifications Input frequency

50-60 Hz

Specifications Life expectancy

100,000 hours

Other Package dimensions (LxWxH)

325 x 210 x 110 mm

Specifications Standby efficiency

ErP 2013 (<0.45W @230. VAC, 45 mA load on +5Vsb)

Specifications Semi-passive operation

Yes, user selectable (Zero RPM)

Specifications Sleep state compliance

C6/C7

Connectors ATX12V 4+4 pin / EPS12V 8-pin

2

Maximum operating temperature (full load)

50°C

Specifications Approvals & certifications

CE, FCC, TUV, cTUVus, EAC, RCM, CCC, BSMI, CB, KC+KCC

Specifications Maximum operating temperature (full load)

50°C

Cable Configuration (length in mm between connectors) SATA

400+150+150+150 mm & 650+150mm

Cable Configuration (length in mm between connectors) Peripheral

400+150+150+150 mm

Cable Configuration (length in mm between connectors) ATX 20+4 pin

600 mm

Cable Configuration (length in mm between connectors) EPS12V 8-pin

600 mm

Cable Configuration (length in mm between connectors) PCIe 6+2 pin

550 + 120 mm

Cable Configuration (length in mm between connectors) ATX 12V 4+4 pin

700 mm
