Typ

Fan

Ljudnivå

18.9 dBA

Fläktstorlek

25 mm

Antal fläktar

1

Fläkthastighet

1000 RPM

Dimensioner

140 × 140 × 25 mm

Lagertyp

Hydraulic

Övriga specifikationer

EAN

7350041083313

UPC

817301013314

MTBF

40,000 hours

Size

140 x 140 x 25 mm

Airflow

68.4 CFM

Bearing

Hydraulic

Other EAN

7350041083313

Other UPC

817301013314

Cable type

Black ribbon cable

Fan weight

142 g

Noise level

18.9 dB (A)

Cable length

500 mm

Fan Connector

3-pin

Package weight

190 g

Fan input power

1.7 W

Static pressure

0.71 mm H2O

Number of blades

7

Package contents

Dynamic Series fan, Screw pack with 4 metal fan screws

Rotational speed

1000 RPM

Fan input voltage

12 V

Screw hole pattern

125 x 125 mm

Specifications MTBF

40,000 hours

Fan starting voltage

4 V

Other Package weight

190 g

Product code (Black)

FD-FAN-DYN-GP14-BK

Product code (White)

FD-FAN-DYN-GP14-WT

Fan max input current

0.20 A

Specifications Airflow

68.4 CFM

Specifications Cable type

Black ribbon cable

Specifications Fan weight

142 g

Other Product code (Black)

FD-FAN-DYN-GP14-BK

Other Product code (White)

FD-FAN-DYN-GP14-WT

Specifications Cable length

500 mm

Specifications Fan Connector

3-pin

Specifications Fan input power

1.7 W

Specifications Static pressure

0.71 mm H2O

Specifications Number of blades

7

Specifications Fan input voltage

12 V

Specifications Screw hole pattern

125 x 125 mm

Specifications Fan starting voltage

4 V

Specifications Fan max input current

0.20 A

Package dimensions (Excluding hanging tab)

167 x 142 x 26 mm

Package dimensions (Including hanging tab)

200 x 142 x 26 mm

Other Package dimensions (Excluding hanging tab)

167 x 142 x 26 mm

Other Package dimensions (Including hanging tab)

200 x 142 x 26 mm
