Vikt

7.2 kg

Material

Steel, Tempered Glass

Dimensioner

399 × 212 × 440 mm

Formfaktor

ATX, mATX, ITX

Medföljande fläktar

front: 1x Dynamic X2 GP-12; rear: 1x Dynamic X2 GP-12

Max GPU-längd

315 mm

Max PSU-längd

175 mm

Sidopanel

Tempered Glass

Expansionsplatser

7

Max kylarhöjd

172 mm

Radiatorstöd (topp)

120mm / 240mm

Radiatorstöd (front)

120mm / 240mm / 360mm / 140mm / 280mm

Övriga specifikationer

EAN

7350041085683

UPC

817301015684

Volume

36.9 liters

Top fan

2x 120/140

Rear fan

1x 120 (1x Dynamic X2 GP-12 included)

Warranty

2 Years

Front fan

3x 120 or 2x 140 (1x Dynamic X2 GP-12 included)

Other EAN

7350041085683

Other UPC

817301015684

Bottom fan

1x 120

Net weight

7.2 kg

Front ports

2x USB 3.0, Audio in/out, Power button with LED, HDD activity LED, Reset button

Dust filters

Bottom fan + PSU, Front fans, Top panel (optional)

Product code

FD-CA-DEF-C-BK-TG

Top radiator

120/240 mm (max component height on motherboard 40 mm)

Rear radiator

120 mm (max width 125 mm)

Front radiator

120/240/360 mm or 140/280 mm

GPU max length

Max 315 mm with front fan mounted

Other Warranty

2 Years

PSU max length

Maximum 175 mm recommended

Package weight

8.7 kg

Expansion slots

7

Left side panel

Tempered Glass

Package contents

Define C TG computer case; User manual; Accessory box; Optional top filter

Right side panel

Industrial sound-dampened steel

Total fan mounts

7

Dimensions Volume

36.9 liters

Power supply type

ATX

Other Product code

FD-CA-DEF-C-BK-TG

Cable routing space

15-35 mm

Captive thumbscrews

Both side panels, SSD brackets

Fixed Velcro straps

Yes

CPU cooler max height

172 mm

Cable routing grommets

Yes

Other Package contents

Define C TG computer case; User manual; Accessory box; Optional top filter

Specifications Top fan

2x 120/140

Case dimensions (LxWxH)

399 x 212 x 440 mm

Dimensions Package weight

8.7 kg

Motherboard compatibility

ATX, mATX, ITX

Specifications Bottom fan

1x 120

Package dimensions (LxWxH)

543 x 295 x 484 mm

Specifications Front ports

2x USB 3.0, Audio in/out, Power button with LED, HDD activity LED, Reset button

3.5" or 2.5" Drive capacity

2

Compatibility Rear radiator

120 mm (max width 125 mm)

Specifications Dust filters

Bottom fan + PSU, Front fans, Top panel (optional)

Dedicated 2.5" drive capacity

3 (Maximum 2.5" drive thickness is 10 mm)

Compatibility Power supply type

ATX

Compatibility Cable routing space

15-35 mm

Specifications Captive thumbscrews

Both side panels, SSD brackets

Specifications Fixed Velcro straps

Yes

Dimensions Package dimensions (LxWxH)

543 x 295 x 484 mm

Specifications Cable routing grommets

Yes

Specifications 3.5" or 2.5" Drive capacity

2

Specifications Dedicated 2.5" drive capacity

3 (Maximum 2.5" drive thickness is 10 mm)

Case dimensions - with feet/protrusions/screws

413 x 217 x 453 mm

Dimensions Case dimensions - with feet/protrusions/screws

413 x 217 x 453 mm
