Effekt

1100 W

ATX-version

ATX 12V Ver. 3.1 | ATX 3.1

Dimensioner

180 × 150 × 86 mm

Effektivitet

80+ Platinum

Formfaktor

ATX

Skydd

OPP/ OVP/ OTP/ OCP/ SCP/ UVP/ Surge & Inrush Protection

EPS-kontakter

2

SATA-kontakter

12

12VHPWR-kontakter

1

PCIe 8-pin-kontakter

4

Övriga specifikationer

PFC

Active PFC

MTBF

>100,000 Hours

Model

MPS-B001-AZBP

Watts

1100W

Series

X Series

Summary

• Fanless Design for Absolute Silence • Patented Heat Pipe Dissipation • Minimize Electromagnetic Noise • Industrial-Grade Infineon IC • Digital Power Management System • 15-year warranty

Category

Above 750W

Subtitle

PRECISE SILENT POWER

Efficiency

≥ 94% @ Typical Load

Regulatory

TUV, CE, CCC, EAC, RCM, UKCA/BIS, KC (based on region's request.)

ATX Version

ATX 12V Ver. 3.1 | ATX 3.1

Form Factor

ATX

Protections

OPP/ OVP/ OTP/ OCP/ SCP/ UVP/ Surge & Inrush Protection

Category key

natdel

Hold Up Time

≥ 16ms

Category path

global/catalog/power-supplies/x-series/

Input Current

6.1A (Max.)

Input Voltage

200-240V

80 PLUS Rating

80 PLUS Platinum

ErP 2014 Lot 3

Yes

Shopify handle

x-silent-edge-platinum-1100

Storyblok slug

x-silent-edge-platinum-1100

Input Frequency

50-60Hz

SATA Connectors

12

Power Good Signal

100 - 150 ms

USB 10P Connector

1

12V-2x6 Connectors

1

80 Plus Efficiency

Platinum

EPS 8 Pin Connector

1

Input Voltage Range

230V

ATX 24 Pin Connectors

1

Operating Temperature

0-40°C

PMBus 5 Pin Connector

1

Dimensions (L x W x H)

180 x 150 x 86 mm

EPS 4+4 Pin Connectors

1

PCI-e 6+2 Pin Connectors

4

Peripheral 4 Pin Connectors

4

External Fan 4Pin Connectors

1
