Fläktstorlek

120 mm

Modulär

Full

Effekt

2000 W

ATX-version

ATX 12V Ver. 3.1

Dimensioner

180 × 150 × 86 mm

Effektivitet

80+ Platinum

Formfaktor

ATX

Skydd

OPP/ OVP/ OTP/ OCP/ SCP/ UVP/ Surge & Inrush Protection

EPS-kontakter

2

SATA-kontakter

12

12VHPWR-kontakter

2

PCIe 8-pin-kontakter

4

Övriga specifikationer

PFC

Active PFC

MTBF

>100,000 Hours

Model

MPS-K001-AFBP

Watts

2000W

Series

X Series

Modular

Fully Modular

Summary

• Advanced aluminum thermal structure • 80 Plus Platinum efficiency certification • ATX 3.1 support & two durable 12V-2x6 cables • Dual 40 series GPU support • Digital Power Management System • 10-year warranty

Category

Above 750W

Fan Size

120mm

Subtitle

UNLEASH NEXT-GEN MIGHT

Fan Speed

2500 RPM

Efficiency

≥ 94% @ Typical Load

Regulatory

cUL, TUV, CE, FCC, BSMI, CCC, EAC, RCM, UKCA/BIS, KC (based on region's request.)

ATX Version

ATX 12V Ver. 3.1

Fan Bearing

FDB

Form Factor

ATX

Protections

OPP/ OVP/ OTP/ OCP/ SCP/ UVP/ Surge & Inrush Protection

Category key

natdel

Hold Up Time

≥ 16ms

Category path

global/catalog/power-supplies/x-series/

Input Current

16A (Max)

Input Voltage

115 - 240V (115 - 240V for 1600W / 200 - 240V for 2000W)

80 PLUS Rating

80 PLUS Platinum of EU Internal

ErP 2014 Lot 3

Yes

Shopify handle

x-mighty-platinum-2000

Storyblok slug

x-mighty-2000

Input Frequency

50-60Hz

SATA Connectors

12

Power Good Signal

100 - 150 ms

USB 10P Connector

1

12V-2x6 Connectors

2

80 Plus Efficiency

Platinum

EPS 8 Pin Connector

1

ATX 24 Pin Connectors

1

Operating Temperature

0-50°C

PMBus 5 Pin Connector

1

Dimensions (L x W x H)

180 x 150 x 86 mm

EPS 4+4 Pin Connectors

1

PCI-e 6+2 Pin Connectors

4

Peripheral 4 Pin Connectors

4
