Fläktstorlek

92 mm

Modulär

Full

Effekt

1300 W

ATX-version

SFX 12V Ver. 3.42 | ATX 3.0

Dimensioner

100 × 125 × 63.5 mm

Effektivitet

80+ Platinum

Formfaktor

SFX

Skydd

OPP/ OVP/ OTP/ OCP/ SCP/ UVP/ Surge & Inrush Protection

EPS-kontakter

2

SATA-kontakter

8

PCIe 8-pin-kontakter

3

Övriga specifikationer

PFC

Active PFC

MTBF

>100,000 Hours

Model

MPZ-D001-SFBP-B**

Watts

1300W

Series

V SFX Series

Modular

Fully Modular

Summary

• High power density • ATX 3.0 support & a 90-degree 12VHPWR cable • Advanced thermal performance • 80 Plus Platinum efficiency • Fully modular cabling • 10-year warranty

Category

Above 750W

Fan Size

92mm

Subtitle

An SFX Revolution

Efficiency

≥ 94% @ Typical Load

Regulatory

TUV, cTUVus, CE, BSMI, FCC, CCC, EAC, UKCA

ATX Version

SFX 12V Ver. 3.42 | ATX 3.0

Fan Bearing

FDB

Form Factor

SFX

Protections

OPP/ OVP/ OTP/ OCP/ SCP/ UVP/ Surge & Inrush Protection

Category key

natdel

Hold Up Time

≥16ms at 60% Load

Category path

global/catalog/power-supplies/v-sfx-series/

Input Current

7.7A (Max.)

Input Voltage

200-240V

80 PLUS Rating

80 PLUS Platinum EU 230V

ErP 2014 Lot 3

Yes

Shopify handle

v-sfx-platinum-1300-230v

Storyblok slug

v-sfx-platinum-1300

Input Frequency

50-60Hz

SATA Connectors

8

12VHPWR Connector

1

Power Good Signal

100 - 150 ms

80 Plus Efficiency

Platinum

EPS 8 Pin Connector

1

Input Voltage Range

230V

ATX 24 Pin Connectors

1

Operating Temperature

0-50°C

Dimensions (L x W x H)

100 x 125 x 63.5 mm

EPS 4+4 Pin Connectors

1

PCI-e 6+2 Pin Connectors

3

Peripheral 4 Pin Connectors

4
