Fläktstorlek

92 mm

Modulär

Full

Effekt

850 W

ATX-version

ATX 3.1 & SFX 12V Ver. 3.42

Dimensioner

100 × 125 × 63.5 mm

Effektivitet

80+ Gold

Formfaktor

SFX

Skydd

OPP/ OVP/ OTP/ OCP/ SCP/ UVP/ Surge & Inrush Protection

EPS-kontakter

2

SATA-kontakter

8

12VHPWR-kontakter

1

PCIe 8-pin-kontakter

4

Övriga specifikationer

PFC

Active PFC

MTBF

>100,000 Hours

Model

MPY-8501-SFHAGV-3E**

Watts

850W

Series

V SFX Series

Modular

Fully Modular

Summary

• Flexible compatibility • ATX 3.1 support & a 90-degree 12V-2x6 cable • 80 PLUS Gold certified • Fully modular cabling • 100% Japanese capacitors • 10-year Warranty

Fan Size

92mm

Subtitle

Small But Mighty

Efficiency

90% @ Typical Load

Regulatory

TUV, cTUVus, CE, BSMI, FCC, CCC, EAC, RCM, CB, UKCA

ATX Version

ATX 3.1 & SFX 12V Ver. 3.42

Fan Bearing

FDB

Form Factor

SFX

Protections

OPP/ OVP/ OTP/ OCP/ SCP/ UVP/ Surge & Inrush Protection

Category key

natdel

Hold Up Time

16ms

Category path

global/catalog/power-supplies/v-sfx-series/

Input Current

12-6A

Input Voltage

100-240V

80 PLUS Rating

80 PLUS Gold

ErP 2014 Lot 3

Yes

Shopify handle

v-sfx-gold-850-atx-3-1

Storyblok slug

v-sfx-gold-850-atx-3-1

Input Frequency

50-60Hz

SATA Connectors

8

Power Good Signal

100 - 500 ms

12V-2x6 Connectors

1

80 Plus Efficiency

Gold

EPS 8 Pin Connector

1

ATX 24 Pin Connectors

1

Operating Temperature

0-50°C

Dimensions (L x W x H)

100 x 125 x 63.5 mm

EPS 4+4 Pin Connectors

1

PCI-e 6+2 Pin Connectors

4

Peripheral 4 Pin Connectors

4
