Fläktstorlek

120 mm

Modulär

Full

Effekt

750 W

ATX-version

ATX 12V Ver. 3.1

Dimensioner

160 × 150 × 86 mm

Effektivitet

80+ Gold

Formfaktor

ATX

Skydd

OPP/ OVP/ OTP/ OCP/ SCP/ UVP/ Surge & Inrush Protection

EPS-kontakter

2

12VHPWR-kontakter

1

PCIe 8-pin-kontakter

4

Övriga specifikationer

PFC

Active PFC

MTBF

>100,000 Hours

Model

MPX-7503-AFAG-2***

Watts

750W

Series

MWE Gold Series

Modular

Fully Modular

Summary

• ATX 3.1 support & a durable 12V-2x6 cable • 80 Plus Gold certified efficiency • Silent fan performance with a zero-RPM mode • Separated thermal technologies • Fully modular cabling • 10-year warranty

Category

Above 750W

Fan Size

120mm

Subtitle

BUILT TO LAST

Fan Speed

2500 RPM

Efficiency

≥90% @ Typical Load

Regulatory

cTUVus, TUV, CE, FCC, BSMI, CCC, EAC, RCM, UKCA, RoHS2.0 / BIS, KC (Based on region's requests.)

ATX Version

ATX 12V Ver. 3.1

Fan Bearing

HDB

Form Factor

ATX

Protections

OPP/ OVP/ OTP/ OCP/ SCP/ UVP/ Surge & Inrush Protection

Category key

natdel

Hold Up Time

≥16ms at 80% Load

Category path

global/catalog/power-supplies/mwe-series/

Input Current

10-5A

Input Voltage

100-240V

80 PLUS Rating

80 PLUS Gold

ErP 2014 Lot 3

Yes

Shopify handle

mwe-gold-v3-750-31

Storyblok slug

mwe-gold-750-v3-atx-3-1

Input Frequency

50-60Hz

Power Good Signal

100 - 150 ms

12V-2x6 Connectors

1

80 Plus Efficiency

Gold

EPS 8 Pin Connector

1

ATX 24 Pin Connectors

1

Operating Temperature

0-40°C

Dimensions (L x W x H)

160 x 150 x 86 mm

EPS 4+4 Pin Connectors

1

PCI-e 6+2 Pin Connectors

4

SATA & Peripheral 4 Pin Connectors

6 (SATA) / 2 (Peripheral)
