Fläktstorlek

140 mm

Modulär

Full

Effekt

1250 W

ATX-version

ATX Rev. 3.1

Dimensioner

180 × 150 × 86 mm

Effektivitet

80+ Gold

Formfaktor

ATX

Skydd

OVP / OPP / SCP / OCP / UVP / OTP / Inrush Protection

EPS-kontakter

2

SATA-kontakter

12

12VHPWR-kontakter

1

PCIe 8-pin-kontakter

3

Övriga specifikationer

PFC

Active PFC

MTBF

>100,000 Hours

Model

MPE-C501-AFCAG-3E**

Watts

1250W

Series

MWE Gold Series

Modular

Fully Modular

Summary

80 PLUS Gold Efficiency High-quality Japanese capacitors 140mm Silent Fan High Temperature Resilience Fully Modular Cabling 10 Year Warranty

Category

Above 750W

Fan Size

140mm

Subtitle

ATX 3.1 Fully Modular 80 PLUS Gold Certified ATX Power Supply Unit

Efficiency

≥90% @ Typical Load

Regulatory

TUV, cTUVus, CE, FCC, BSMI, CCC, EAC, RCM, UKCA, BIS

ATX Version

ATX Rev. 3.1

Fan Bearing

Two Ball Bearing

Form Factor

ATX

Protections

OVP / OPP / SCP / OCP / UVP / OTP / Inrush Protection

Category key

natdel

Hold Up Time

≥16ms at 100% Load

Category path

global/catalog/power-supplies/mwe-series/

Input Current

15-7A

Input Voltage

100-240V

80 PLUS Rating

80 PLUS Gold

ErP 2014 Lot 3

Yes

Shopify handle

mwe-gold-1250-v2-atx3-1

Storyblok slug

mwe-gold-1250-v2-atx-3-1

Input Frequency

50-60Hz

SATA Connectors

12

Power Good Signal

100 - 150 ms

12V-2x6 Connectors

1

80 Plus Efficiency

Gold

EPS 8 Pin Connector

1

ATX 24 Pin Connectors

1

Operating Temperature

0-50°C

Dimensions (L x W x H)

180 x 150 x 86 mm

EPS 4+4 Pin Connectors

1

PCI-e 6+2 Pin Connectors

3

Peripheral 4 Pin Connectors

4
