Front I/O

2x USB 3.2 Gen 1 Type A, 1x USB 3.2 Gen 2x2 Type C, 1x 3.5mm Headset Jack (Audio+Mic)

Chassityp

Mid Tower

Material

SGCC Steel, Aluminum

Dimensioner

531 × 261 × 544mm (Incl. Protrusions), 514 × 244 × 514 mm (Excl. Protrusions)

Formfaktor

EATX

Max 120 mm-fläktar

10

Max 140 mm-fläktar

8

2.5"-fack

3

3.5"-fack

0

Medföljande fläktar

Front: Mobius 140 mm x 3 (non-ARGB) - Available for Black Model Only, SickleFlow ARGB 140 mm x 3 - Available for Silver Model Only; Top: N/A; Rear: Mobius 120 mm x 1 (non-ARGB) - Available for Black Model Only, SickleFlow ARGB 120 mm x 1 - Available for Silver Model Only

Max GPU-längd

485 mm

Max PSU-längd

235 mm

Sidopanel

Tempered Glass

Expansionsplatser

8

Max kylarhöjd

190 mm

Radiatorstöd (topp)

120 / 140 / 240 / 280 / 360 / 420 mm (Up to 420mm if I/O module is moved to the front panel)

Radiatorstöd (front)

120 / 140 / 240 / 280 / 360 / 420 mm (Limit: 458 mm)

Övriga specifikationer

Size

Mid Tower

Series

MasterFrame Series

Volume

73.6 L (Liters Incl. Protrusions)

Summary

Premium open-frame ATX case designed for modular builds, extreme cooling, and total customization through the FreeForm 2.0 platform.

Color(s)

Silver

Subtitle

Premium modular ATX case

Warranty

2 years

Category key

chassi

Dust Filters

Top, Front, Bottom, Right side panel

Model Number

MF600-SGNN-S00

Category path

global/catalog/pc-cases/mid-towers/

Shopify handle

masterframe-600-black

Storyblok slug

masterframe-600

2.5" Drive Bays

3

3.5" Drive Bays

0

Clearance - PSU

235 mm

5.25" Drive Bays

0

Fan Support - Top

3x 120mm, 2x 140mm, 2x 180mm, 1x 200mm

Fan Support - Rear

1x 120mm

Fan Support - Side

3x 120mm, 3x 140mm

Fan Support - Front

3x 120mm, 3x 140mm, 2x 180mm, 2x 200mm

Motherboard Support

Mini-ITX, Mini-DTX, Micro-ATX, ATX , E-ATX*, SSI-CEB* (*Conditional Support)

PCI Expansion Slots

8

Included Accessories

GPU Support Bracket (Available for Black Model Only), GPU Support Bracket / ARGB PWM Hub (Available for Silver Model Only)

Materials - Exterior

SGCC Steel, Aluminum

Power Supply Support

ATX

I/O Panel - USB Ports

2x USB 3.2 Gen 1 Type A, 1x USB 3.2 Gen 2x2 Type C

Clearance - CPU Cooler

190 mm

Dimensions (L x W x H)

531 x 261 x 544mm (Incl. Protrusions), 514 x 244 x 514 mm (Excl. Protrusions)

Radiator Support - Top

120 / 140 / 240 / 280 / 360 / 420 mm (Up to 420mm if I/O module is moved to the front panel)

Radiator Support - Rear

120 mm

Radiator Support - Side

240 / 280 / 360 / 420 mm

Pre-installed Fans - Top

N/A

Radiator Support - Front

120 / 140 / 240 / 280 / 360 / 420 mm (Limit: 458 mm)

Clearance - Graphics Card

L: 485 mm (incl. power connector), H: 190 mm (incl. power connector)

Pre-installed Fans - Rear

Mobius 120 mm x 1 (non-ARGB) - Available for Black Model Only, SickleFlow ARGB 120 mm x 1 - Available for Silver Model Only

I/O Panel - Audio In / Out

1x 3.5mm Headset Jack (Audio+Mic)

Pre-installed Fans - Front

Mobius 140 mm x 3 (non-ARGB) - Available for Black Model Only, SickleFlow ARGB 140 mm x 3 - Available for Silver Model Only

2.5" / 3.5" Drive Bays (Combo)

2

Materials - Side panel (Right / Left)

Tempered Glass / Aluminum

Cable Routing - Behind Motherboard Tray

43 mm
