Front I/O

1x USB 3.2 Gen 2 Type C, 4x USB 3.2 Gen 1 (3.0), 1x 3.5mm 4 Poles Audio Jack, 1x 3.5mm Mic Jack

Chassityp

Full Tower

Material

Mesh, Steel, Plastic

Dimensioner

556 × 279 × 540 mm (Body Size), 666 × 291 × 626 mm (incl. Protrusions)

Formfaktor

EATX

Max 120 mm-fläktar

12

Max 140 mm-fläktar

6

2.5"-fack

12

Medföljande fläktar

Front: HAF 700 EVO: 2x SickleFlow PWM Performance Ed. 200mm, HAF 700 EVO White: 2x SickleFlow White PWM Performance Ed. ARGB 200mm; Rear: HAF 700 EVO: 2x SickleFlow PWM ARGB 120mm, HAF 700 EVO White: 2x SickleFlow White PWM ARGB 120mm; Bottom: HAF 700 EVO: 1x SickleFlow PWM ARGB 120mm, HAF 700 EVO White: 1x SickleFlow White PWM ARGB 120mm

Max GPU-längd

490 mm

Max PSU-längd

200 mm

Sidopanel

Tempered Glass

Expansionsplatser

8

Max kylarhöjd

166 mm

Radiatorstöd (topp)

Up to 2x 360mm / 1x 420mm

Radiatorstöd (front)

Up to 420/360mm

Övriga specifikationer

Note

* For regular 30mm thick radiators, for thicker please reference user manual.

Size

Full Tower

Series

HAF Series

Summary

The HAF 700 EVO truly has no limits as it is drawing inspiration from our ever-growing community of enthusiasts.

Subtitle

Created Only for the Best

Warranty

2 years

Category key

chassi

Dust Filters

Front, Bottom, Side

Model Number

H700E-WGNN-S00

Category path

global/catalog/pc-cases/full-towers/

Exterior Color

Vit

Shopify handle

haf-700-evo

Storyblok slug

haf-700-evo

2.5" Drive Bays

12

Clearance - GFX

490mm / 19.29"

Clearance - PSU

200mm / 7.87"

Expansion Slots

8

5.25" Drive Bays

N/A

Fan Support - Top

2x 200mm, 3x 140mm, 6x 120mm (Remove 480mm bracket)

I/O Panel - Other

1x LED Controller A1 (ARGB Gen2), 1x ARGB/PWM Hub

Fan Support - Rear

2x 120mm

Fan Support - Side

4x 120mm / 3x 140mm

Fan Support - Front

2x 200mm, 3x 120/140mm

Motherboard Support

Mini-ITX, Micro-ATX, ATX, E-ATX, SSI-CEB, SSI-EEB

Fan Support - Bottom

3x 120/140mm

Included Accessories

HAF 700 EVO: Vertical Graphics Card Holder V3 (Include 165mm PCIe 4.0 Riser Cable), HAF 700 EVO White: Universal Graphics Card Holder Kit V3 White

Materials - Exterior

Mesh, Steel, Plastic

Power Supply Support

Bottom Mount, ATX

I/O Panel - USB Ports

1x USB 3.2 Gen 2 Type C, 4x USB 3.2 Gen 1 (3.0)

Clearance - CPU Cooler

166mm / 6.53"

Dimensions (L x W x H)

556 x 279 x 540 mm (Body Size), 666 x 291 x 626 mm (incl. Protrusions)

Radiator Support - Top

Up to 2x 360mm / 1x 420mm

Radiator Support - Rear

Up to 240mm

Radiator Support - Side

Up to 480/420mm

Radiator Support - Front

Up to 420/360mm

Pre-installed Fans - Rear

HAF 700 EVO: 2x SickleFlow PWM ARGB 120mm, HAF 700 EVO White: 2x SickleFlow White PWM ARGB 120mm

Radiator Support - Bottom

Up to 420/360mm

I/O Panel - Audio In / Out

1x 3.5mm 4 Poles Audio Jack, 1x 3.5mm Mic Jack

Pre-installed Fans - Front

HAF 700 EVO: 2x SickleFlow PWM Performance Ed. 200mm, HAF 700 EVO White: 2x SickleFlow White PWM Performance Ed. ARGB 200mm

Materials - Left Side Panel

Tempered Glass, Steel

Pre-installed Fans - Bottom

HAF 700 EVO: 1x SickleFlow PWM ARGB 120mm, HAF 700 EVO White: 1x SickleFlow White PWM ARGB 120mm

2.5" / 3.5" Drive Bays (Combo)

12

Cable Routing - Behind Motherboard Tray

90-101mm
