Front I/O

1x USB 3.2 Gen1 Type A, 1x USB 3.2 Gen1 Type C​, 1x 3.5mm Combo (Audio + Mic)​

Chassityp

Mini Tower

Material

Steel

Dimensioner

390 × 203.5 × 430mm​ (Incl. Protrusions), 377 × 203.5 × 410mm​ (Excl. Protrusions)

Formfaktor

ATX

Max 120 mm-fläktar

6

Max 140 mm-fläktar

2

2.5"-fack

1

3.5"-fack

1

Medföljande fläktar

Front: Black: 3x 120mm ARGB Black​​, White: 3x 120mm ARGB White; Top: N/A; Rear: N/A

Max GPU-längd

365 mm

Max PSU-längd

160 mm

Sidopanel

TG / Steel

Expansionsplatser

4

Max kylarhöjd

164 mm

Radiatorstöd (topp)

120 / 140 / 240 / 280mm

Radiatorstöd (front)

120 / 240 / *360 mm (*Supported within 60mm thickness)​

Övriga specifikationer

Size

Mini Tower

Series

Elite Series

Summary

High in value and attention to detail, Cooler Master's Elite 302 offers users a cost effective, space conscious solution to gaming and computing needs. Elite 302 features a large intake grill and 3x 120mm ARGB fans to ensure a smooth, and efficient running system. The fully black coating and included PSU cover allows for clean builds that are visually appealing as well as functional.

Subtitle

Effortless Efficiency

Warranty

2 years

Category key

chassi

Dust Filters

Top / Bottom / Front

Model Number

ELITE 302: E302-KGNN-S00 | ELITE 302 White: E302-WGNN-S00

Cable Routing

18.5mm

Category path

global/catalog/pc-cases/mini-towers/

Exterior Color

Black, White

Shopify handle

elite-302

Storyblok slug

elite-302

2.5" Drive Bays

1 (Max. 2)

3.5" Drive Bays

1

Clearance - GFX

365mm (without front fans & radiator)

Clearance - PSU

160mm

Expansion Slots

4

5.25" Drive Bays

N/A

Fan Support - Top

2x 120mm / 2x 140mm

Fan Support - Rear

1x 120mm

Fan Support - Front

3x 120mm

Motherboard Support

Mini-ITX, Micro-ATX

Materials - Exterior

Steel

Power Supply Support

ATX

I/O Panel - USB Ports

1x USB 3.2 Gen1 Type A, 1x USB 3.2 Gen1 Type C

Clearance - CPU Cooler

163.5mm

Dimensions (L x W x H)

390 x 203.5 x 430mm (Incl. Protrusions), 377 x 203.5 x 410mm (Excl. Protrusions)

Radiator Support - Top

120 / 140 / 240 / 280mm

Radiator Support - Rear

120mm

Pre-installed Fans - Top

N/A

Radiator Support - Front

120 / 240 / *360 mm (*Supported within 60mm thickness)

Pre-installed Fans - Rear

N/A

I/O Panel - Audio In / Out

1x 3.5mm Combo (Audio + Mic)

Pre-installed Fans - Front

Black: 3x 120mm ARGB Black, White: 3x 120mm ARGB White

Volume (incl. Protrusions)

34.13L

Materials - Side panel (Right / Left)

TG / Steel
