390
203.5
430 mm incl protrusions / 377
203.5
410 mm excl protrusions
Formfaktor
ATX
Max 120 mm-fläktar
6
Max 140 mm-fläktar
2
2.5"-fack
1
3.5"-fack
1
Medföljande fläktar
Rear: 1x 120mm Black Fan
Övriga specifikationer
Size
Mini Tower
Series
Elite Series
Volume
34.13L (incl. Protrusions)
Summary
High in value and attention to detail, Cooler Master's Elite 301 lite offers users a cost effective, space conscious solution to gaming and computing needs. Elite 301 features a large intake grill to ensure a smooth, and efficient running system. The fully black coating and included PSU cover allows for clean builds that are visually appealing as well as functional.
Elite 301 White Lite High in value and attention to detail, Cooler Master's Elite 301 lite offers users a cost effective, space conscious solution to gaming and computing needs. Elite 301 features a large intake grill to ensure a smooth, and efficient running system. The fully black coating and included PSU cover allows for clean builds that are visually appealing as well as functional. Remove Product? Tool-less Intake Panel Constructed with a substantially large, unrestricted intake grill to ensure that the system runs cool and efficiently. The front panel could be easily removed by magnets, making it easier for daily maintenance. Versatile Cooling Options Supports up to six fans and 280mm radiator to ensure that performance is not compromised. Large Support, Minimized Footprint Despite its compact size, Elite 301 lite supports up to 365mm graphics cards, 163.5mm CPU Coolers, providing solid potential for future upgrades. Breathable Power Supply Shroud The PSU cover is ventilated on top of the power supply location, allowing actively cooled units to be installed in multiple orientations, while maintaining support for passively cooled power supplies. Specifications Downloads Product Sheet Product Sheet - Japanese Edition Manual About Us Support Join Us Resource Center
Source page type
sfcc-html
Fan Support - Top
2x 120mm / 2x 140mm
Fan Support - Rear
1 x 120mm
Fan Support - Front
3x 120mm
Motherboard Support
ITX / Micro ATX
Power Supply Support
ATX
Clearance - CPU Cooler
163.5mm
Dimensions (L x W x H)
390 x 203.5 x 430mm incl protrusions / 377 x 203.5 x 410mm excl protrusions
