Front I/O

1x 3.5mm Combo

Chassityp

Mini Tower

Dimensioner

390 × 203.5 × 430mm incl protrusions / 377 × 203.5 × 410mm excl protrusions

Formfaktor

ATX

Max 120 mm-fläktar

6

Max 140 mm-fläktar

2

2.5"-fack

1

3.5"-fack

1

Medföljande fläktar

Rear: 1x 120mm Black Fan

Max GPU-längd

365 mm

Max PSU-längd

160 mm

Expansionsplatser

4

Max kylarhöjd

164 mm

Radiatorstöd (topp)

120 / 140 / 240 / 280mm

Radiatorstöd (front)

120 / 240mm

Övriga specifikationer

Size

Mini Tower

Series

Elite Series

Volume

34.13L (incl. Protrusions)

Summary

High in value and attention to detail, Cooler Master's Elite 301 lite offers users a cost effective, space conscious solution to gaming and computing needs. Elite 301 features a large intake grill to ensure a smooth, and efficient running system. The fully black coating and included PSU cover allows for clean builds that are visually appealing as well as functional.

Subtitle

Effortless Efficiency

Warranty

2 years

I/O Panel

1x USB 3.2 Gen 1 Type-A | 1x USB 3.2 Gen 1 Type-C

Materials

Steel, Plastic, Tempered Glass (Left Side Panel)

Category key

chassi

Dust Filters

Top / Bottom / Front

Model Number

E301L-WGNN-S00

Cable Routing

18.5mm

Category path

global/catalog/pc-cases/mini-towers/

Exterior Color

White

Shopify handle

elite-301-white-lite

Storyblok slug

elite-301-white-lite

2.5" Drive Bays

1 (Max. 2)

3.5" Drive Bays

1

Clearance - GFX

365mm (without front fans & radiator)

Clearance - PSU

160mm

Expansion Slots

4

Fan Support - Top

2x 120mm / 2x 140mm

Fan Support - Rear

1 x 120mm

Fan Support - Front

3x 120mm

Motherboard Support

ITX / Micro ATX

Power Supply Support

ATX

Clearance - CPU Cooler

163.5mm

Dimensions (L x W x H)

390 x 203.5 x 430mm incl protrusions / 377 x 203.5 x 410mm excl protrusions

Radiator Support - Top

120 / 140 / 240 / 280mm

Radiator Support - Rear

120mm

Radiator Support - Front

120 / 240mm

Pre-installed Fans - Rear

1x 120mm Black Fan

I/O Panel - Audio In / Out

1x 3.5mm Combo
