Elite 301

Front I/O

1x 3.5mm Combo

Effekt

301 W

Chassityp

Mini Tower

Garanti

2 years

Dimensioner

390 203.5 430 mm incl protrusions / 377 203.5 410 mm excl protrusions

Formfaktor

ATX

Max 120 mm-fläktar

6

Max 140 mm-fläktar

2

2.5"-fack

1

3.5"-fack

1

Medföljande fläktar

Front: 3x 120mm CF120 ARGB

Max GPU-längd

365 mm

Max PSU-längd

160 mm

Expansionsplatser

4

Max kylarhöjd

164 mm

Radiatorstöd (topp)

120 / 140 / 240 / 280mm

Radiatorstöd (front)

120 / 240mm

Övriga specifikationer

Size

Mini Tower

Series

Elite Series

Summary

High in value and attention to detail, Cooler Master's Elite 301 offers users a cost effective, space conscious solution to gaming and computing needs. Elite 301 features a large intake grill and 3x 120mm ARGB fans to ensure a smooth, and efficient running system. The fully black coating and included PSU cover allows for clean builds that are visually appealing as well as functional.

Subtitle

Effortless Efficiency

Warranty

2 years

I/O Panel

1x USB 3.2 Gen 1 Type-A | 1x USB 3.2 Gen 1 Type-C

Materials

Steel, Plastic, Tempered Glass (Left Side Panel)

Product URL

https://www.coolermaster.com/en-global/products/elite-301.html

Category key

natdel

Dust Filters

Top / Bottom / Front

Model Number

E301-KGNN-S00

Product slug

elite-301

Cable Routing

18.5mm

Category path

global/catalog/pc-cases/mini-towers/

Exterior Color

Black

Shopify handle

elite-301

Storyblok slug

elite-301

2.5" Drive Bays

1 (Max. 2)

3.5" Drive Bays

1

Clearance - GFX

365mm (without front fans & radiator)

Clearance - PSU

160mm

Expansion Slots

4

Indexed content

Elite 301 Commerce Cloud Storefront Reference Architecture Remove Product? Tool-less Intake Panel Constructed with a substantially large, unrestricted intake grill to ensure that the system runs cool and efficiently. The front panel could be easily removed by magnets, making it easier for daily maintenance. Versatile Cooling Options Supports up to six fans and 280mm radiator to ensure that performance is not compromised. Unrestricted Air Flow Pre-installed with 3x 120mm ARGB fans, providing considerable airflow and adds a layer of style to the system. Breathable Power Supply Shroud The PSU cover is ventilated on top of the power supply location, allowing actively cooled units to be installed in multiple orientations, while maintaining support for passively cooled power supplies. Large Support, Minimized Footprint Specifications Downloads Product Sheet Product Sheet - Japanese Edition Manual About Us Support Join Us Resource Center

Source page type

sfcc-html

Fan Support - Top

2x 120mm / 2x 140mm

Fan Support - Rear

1 x 120mm

Fan Support - Front

3x 120mm

Motherboard Support

ITX / Micro ATX

Power Supply Support

ATX

Clearance - CPU Cooler

163.5mm

Dimensions (L x W x H)

390 x 203.5 x 430mm incl protrusions / 377 x 203.5 x 410mm excl protrusions

Radiator Support - Top

120 / 140 / 240 / 280mm

Radiator Support - Rear

120mm

Radiator Support - Front

120 / 240mm

I/O Panel - Audio In / Out

1x 3.5mm Combo

Pre-installed Fans - Front

3x 120mm CF120 ARGB
