Chassityp

Full Tower

Dimensioner

650 × 306 × 651mm / 25.6 × 12.0 × 25.6 inch

Formfaktor

EATX

2.5"-fack

4

Medföljande fläktar

Front: 3x 140mm PWM Fan (Speed: 1200RPM / Connector: 4Pin); Rear: 1x 140mm PWM Fan (Speed: 1200RPM / Connector: 4Pin)

Max GPU-längd

490 mm

Expansionsplatser

8

Max kylarhöjd

198 mm

Radiatorstöd (topp)

120mm, 140mm, 240mm, 280mm, 360mm, 420mm (remove ODD, maximum thickness clearance 70mm)

Radiatorstöd (front)

120mm, 140mm, 240mm, 280mm, 360mm, 420mm (remove ODD)

Övriga specifikationer

Size

Full Tower

Series

COSMOS Series

Summary

Highly Versatile Layout, Graphics Card Mounting with Riser Cable, Addressable RGB Lighting, Extensive Cable Cover System, Aluminum Panels & Handles, Versatile Liquid Cooling Support, Rich Connectivity, Curved Tempered Glass Side Panel

Color(s)

Vit

Subtitle

Raising the Bar(s)

Accessories

Riser Cable PCIe 4.0 x16 - 400mm (Compatible with PCI Express 4.0 Gen 3 and below)

Category key

chassi

Model Number

MCC-C700M-WG5N-S00

Category path

global/catalog/pc-cases/full-towers/

Shopify handle

cosmos-c700m

Storyblok slug

cosmos-c700m

Clearance - GFX

490mm (w/o 3.5" HDD BRK), 320mm (w/ 3.5" HDD BRK)

Expansion Slots

8

5.25" Drive Bays

1

Drive Bays - SSD

4

Materials - Body

Steel

Fan Support - Top

3x 120/140mm

Fan Support - Rear

1x 120/140mm

Fan Support - Front

3x 120/140mm

Motherboard Support

Mini-ITX, Micro-ATX, ATX, E-ATX (support up to 12" x 10.7")

Fan Support - Bottom

2x 120/140mm (Bracket Needed)

Clearance - CPU Cooler

198mm

Dimensions (L x W x H)

650 x 306 x 651mm / 25.6 x 12.0 x 25.6 inch

Materials - Side Panel

Curved Tempered Glass, Steel

Radiator Support - Top

120mm, 140mm, 240mm, 280mm, 360mm, 420mm (remove ODD, maximum thickness clearance 70mm)

Radiator Support - Rear

120mm, 140mm

Radiator Support - Front

120mm, 140mm, 240mm, 280mm, 360mm, 420mm (remove ODD)

Pre-installed Fans - Rear

1x 140mm PWM Fan (Speed: 1200RPM / Connector: 4Pin)

Radiator Support - Bottom

120mm, 140mm, 240mm

I/O Port - Fans / Lighting

Fan Speed Control Button, ARGB Control Button

Pre-installed Fans - Front

3x 140mm PWM Fan (Speed: 1200RPM / Connector: 4Pin)

2.5" / 3.5" Drive Bays (Combo)

4+1 (In The Accessory Box)

I/O Port - Audio - 3.5mm Mic Jack

1

I/O Port - USB Ports / USB 3.0 Type-A

4

I/O Port - USB Ports / USB 3.1 Type-C

1

I/O Port - Audio - 3.5mm Headset Jack (Audio+Mic)

1
