Effekt

850 W

Dimensioner

160 × 150 × 86 mm

Effektivitet

80+ Platinum

Skydd

OPP/OVP/UVP/SCP/OCP/OTP

EPS-kontakter

2

SATA-kontakter

10

12VHPWR-kontakter

1

PCIe 8-pin-kontakter

3

Övriga specifikationer

MTBF

>120,000 hrs @ 25°C

Weight

1.865kg (Single)

PFC Type

Active PFC

AURA SYNC

ARGB

Maximum Load

20A 20A 71A 0.3A 3A

Combined Load

100W 100W 852W 3.6W 15W

0dB Fan Button

Yes. When the Button is ON, the fan will only spin up when the system reaches a certain load. When the Button is OFF, the fan will continuously spin at all load levels.

0dB Technology

Supported. The fan shuts off entirely when the PSU is under certain load

AC Input Range

100-240Vac

Package Contents

Power Cord x 1 Motherboard Power Cable x 1 (610mm) CPU Cable x 2 (650mm) PCI-E Gen 5 16-pin Cable x 1 (675mm) PCI-E Cable 1-to-1 x 3 (675mm) SATA Cable 1-to-4 x 2 (400+120+120+120 mm) SATA Cable 1-to-2 x 1 (450+120mm) Peripheral 1-to-3 x 2 (450+120+120mm) Addressable RGB cable x1 (800mm) ROG sticker x 1 ROG cable tie x 4 Sleeved Cable Combs (6-pin) x 2 Sleeved Cable Combs (8-pin) x 6 Sleeved Cable Combs (24-pin) x 2 Chassis Screws Package x 1 Cable Tie x 10 User Manual x 1

DC Output Voltage

+3.3V +5V +12V -12V +5Vsb

Hazardous Materials

ROHS

Cybenetics Noise Level Certification

A++
