ROG STRIX B860-I GAMING WIFI

Övriga specifikationer

EAN

4711387815991

Typ

Ljudkort

USB

Rear USB (Total 8 ports) 1 x Thunderbolt 4 port (1 x USB Type-C) 1 x USB 20Gbps port (1 x USB Type-C) 1 x USB 10Gbps ports (1 x Type-A) 3 x USB 5Gbps ports (3 x Type-A) 2 x USB 2.0 ports (2 x Type-A) Front USB (Total 5 ports) 1 x USB 10Gbps connector (supports USB Type-C) 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports 1 x USB 2.0 header supports 2 additional USB 2.0 ports * USB Type-C power delivery output: max. 5V/3A

BIOS

256Mb Flash ROM, UEFI AMI BIOS

Ljud

High Definition Audio (8-kanalig)

Modell

ROG STRIX B860-I GAMING WIFI

Lagring

Serial ATA-600 (RAID), M.2-uttag

BIOS-typ

AMI

Kretstyp

Intel B860

Nätverk

Bluetooth 5.4, 2.5 Gigabit Ethernet, 802.11a/b/g/n/ac/ax/be (Wi-Fi 7)

Egenskaper

Intel Extreme Memory Profiles (XMP), Minnesarkitektur med dubbel kanal

Formfaktor

Mini ITX

Produkttyp

Moderkort

Accessories

Cables 2 x SATA 6Gb/s cables 1 x ROG USB2.0 splitter cable 1 x Panel cable Miscellaneous 1 x ASUS WiFi Q-Antenna 1 x Cable ties package 1 x M.2 Q-Latch package 1 x Screw package for M.2 SSD 1 x M.2 Bracket 1 x ROG key chain 1 x ROG Strix stickers Documentation 1 x Quick start guide

Audio Codec

Realtek ALC1220P

Gränssnitt

2 x antenn, 1 x DisplayPort, 1 x SPDIF-utgång, 2 x USB 2.0, 1 x LAN (2.5Gigabit Ethernet), 1 x mikrofon - mini-jack, 1 x USB 3.2 Gen 2, 1 x Thunderbolt 4, 3 x USB 3.2 Gen 1, 1 x USB-C 3.2 Gen2x2, 1 x HDMI, 1 x ljudutgång - mini-jack

Produktlinje

ASUS

USB/FireWire

USB 3.2 Gen 1, USB-C 3.2 Gen 2x2, USB4, USB 3.2 Gen 2

Manageability

WOL by PME, UEFI PXE

Paketdetaljer

Låda

Lagringsportar

4 x SATA-600 (RAID), 2 x M.2

News & Updates

Please see the updated OS support requirements for the Intel Core Ultra 200S Series below: •Intel Core Ultra 200S Series: Supports Windows 10 (version 21H2 and later) and Windows 11 (version 22H2 and later). •Intel Core Ultra 200S Plus Series: Windows 11 (version 25H2 and later) for full compatibility., Please visit our GLOBAL website to check anddownload the latest updates.

BIOS-egenskaper

ASUS EZ Flash, UEFI BIOS, ASUS UEFI BIOS EZ-läge

RAID-egenskaper

Intel Rapid Storage Technology

RAM-kortplatser

2 DIMM-kortplatser

Strömkontakter

8-pin ATX12V-kontakt, 24-pin kontakt för huvudström

Operating System

Windows 11 (22H2 & later)

Processor-socket

LGA1851-uttag

Special Features

Extreme Engine Digi+ - 5K Black metallic capacitors ASUS Q-Design - PCIe Slot Q-Release Slim (with PCIe SafeSlot) - M.2 Q-Latch - Q-Antenna - Q-Dashboard - Q-DIMM - Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]) - Q-Slot ASUS Thermal Solution - M.2 heatsink backplate - M.2 heatsink - VRM heatsink design ASUS EZ DIY - Clear CMOS button - CPU Socket lever protector - ProCool - Pre-mounted I/O shield - SafeSlot - SafeDIMM Aura Sync - Addressable Gen2 headers

Software Features

ROG Exclusive Software - ROG CPU-Z - Dolby Atmos ASUS Exclusive Software Armoury Crate - Aura Creator - Aura Sync - Fan Xpert 4 - GameFirst - Power Saving AIDA64 Extreme (60 days free trial) HWiNFO ASUS AI Advisor ASUS DriverHub ASUS GlideX TurboV Core Adobe Creative Cloud (Free Trial) Norton 360 for Gamers (60 Days Free Trial) WinRAR (40 Days Free Trial) UEFI BIOS ASUS EZ DIY - ASUS CrashFree BIOS 3 - ASUS EZ Flash - ASUS UEFI BIOS EZ Mode - ASUS MyHotkey NPU Boost

Datalänkprotokoll

IEEE 802.11a, IEEE 802.11ac, IEEE 802.11n, Gigabit Ethernet, Bluetooth 5.4, IEEE 802.11b, IEEE 802.11be (Wi-Fi 7), IEEE 802.11g, 2.5 Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6E), Fast Ethernet, Ethernet

Hårdvaruegenskaper

Clear CMOS-knapp, CUDIMM stöds, PCIe Slot Q-Release, ROG CPU-Z, NPU Boost, Q-Slot, 5K Black Metallic Capacitors, ASUS EZ DIY, Q-Antenna, Q-DIMM, ASUS SafeDIMM, ASUS Aura Sync, DIY Friendly Design, ASUS Q-Design, Q-Dashboard, Förmonterat I/O-skydd, M.2 kylfläns, VRM-kylelementskonstruktion, Intel Turbo Boost Max Technology 3.0, Intel Turbo Boost-teknologi 2.0, ASUS ProCool, ASUS SafeSlot, CPU-uttagsskydd, Q-LED, ASUS Extreme Engine Digi+, M.2 Q-Latch, ASUS Enhanced Memory Profile (AEMP) III, M.2 bakre kylelementsplåt, AI Nätverk II, 10+1+2+1-fasig strömdesign

Interna gränssnitt

1 x ljud - header, 1 x USB-C 3.2 Gen 2 - header, 2 x USB 2.0 - header, 2 x USB 3.2 Gen 1 - header

Lagringsgränssnitt

PCIe 4.0 -kontakter: 1 x M.2, SATA-600 -kontakter: 4 x 7 pin Seriell ATA - RAID 0 / RAID 1 / RAID 10 / RAID 5, PCIe 5.0 -kontakter: 1 x M.2

Medföljande kablar

1 x panelkabel, 1 x USB 2.0-delningskabel, 2 x Seriell ATA-kabel

Back Panel I/O Ports

1 x Thunderbolt 4 port (1 x USB Type-C) 1 x USB 20Gbps port (1 x USB Type-C) 1 x USB 10Gbps ports (1 x Type-A) 3 x USB 5Gbps ports (3 x Type-A) 2 x USB 2.0 ports (2 x Type-A) 1 x DisplayPort 1 x HDMI port 1 x Wi-Fi module 1 x Intel 2.5Gb Ethernet port 2 x Audio jacks 1 x Optical S/PDIF out port 1 x Clear CMOS button

Expansionskortplatser

1 x M.2 socket (2242/2260/2280 M.2 Key M-plats), 1 x M.2 socket (2260/2280 M.2 Key M-plats), 1 x CPU, 2 x DIMM 288-stift, 1 x PCIe 5.0 x16

RAM-teknik som stöds

DDR5 SDRAM

Standarder som följs

HD-ljud, Dolby Atmos

Inkluderade tillbehör

ROG-nyckelring, M.2-fäste, M.2-skruvpaket, ROG Strix klistermärke, M.2 Q-Latch, Kabelband, ASUS Wi-Fi Q-antenna

Programvara inkluderad

HWiNFO, TurboV Core, WinRAR (40 days trial), Armoury Crate, Adobe Creative Cloud (kostnadsfri provperiod), ASUS GlideX, ASUS DriverHub, Norton 360 för gamers (60 dagars provperiod), ASUS AI Advisor, ASUS Fan Xpert 4, ROG CPU-Z, AIDA64 Extreme (60 dagars testperiod)

Internal I/O Connectors

Fan and Cooling Related 1 x 4-pin CPU Fan header 1 x 4-pin AIO Pump header 1 x 4-pin Chassis Fan headers Power Related 1 x 24-pin Main Power connector 1 x 8-pin +12V CPU Power connector Storage Related 2 x M.2 slots (Key M) 4 x SATA 6Gb/s ports USB 1 x USB 10Gbps connector (supports USB Type-C) 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports 1 x USB 2.0 header supports 2 additional USB 2.0 ports Miscellaneous 2 x Addressable Gen2 headers 1 x Front Panel Audio header (F_AUDIO) 1 x 10-1 pin Front System Panel header 1 x Thermal Sensor header

RAM-hastighet som stöds

4533 MHz (O.C.)

Stöder Ram Integrity Check

Icke ECC

Kompatibla processorkommentarer

Stödjer Intel Core Ultra-processorer (serie 2)

Producentens garanti (månader)

36

USB/FireWire-portkonfiguration (aktiv)

1 x USB4 + 1 x USB-C 3.2 Gen 2x2 + 1 x USB 3.2 Gen 2 + 3 x USB 3.2 Gen 1 + 2 x USB 2.0

USB/FireWire-portkonfiguration (sidhuvud)

1 x USB-C 3.2 Gen 2 + 2 x USB 3.2 Gen 1 + 2 x USB 2.0

RAM som stöds (registrerad eller buffrad)

Klockad oförbufferad, Ej buffrad
