ROG STRIX B650E-I GAMING WIFI

Övriga specifikationer

EAN

4711081957881

Typ

Ljudkort

USB

Rear USB (Total 8 ports) 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C) 5 x USB 3.2 Gen 2 ports (4 x Type-A + 1 x USB Type-C) 2 x USB 2.0 ports (2 x Type-A) Front USB (Total 5 ports) 1 x USB 3.2 Gen 2 connector 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports 1 x USB 2.0 header supports additional 2 USB 2.0 ports

BIOS

256 MbFlash ROM, UEFI AMI BIOS

Ljud

High Definition Audio (8-kanalig)

Modell

ROG Strix B650E-I Gaming WiFi

Chipset

AMD B650E

Lagring

M.2-uttag, Serial ATA-600 (RAID)

BIOS-typ

AMI

Kretstyp

AMD B650

Nätverk

2.5 Gigabit Ethernet, 802.11a/b/g/n/ac/ax (Wi-Fi 6E)

Antal M.2

2 st

Egenskaper

Minnesarkitektur med dubbel kanal, AMD EXPO-teknik

Formfaktor

Mini-ITX

Produkttyp

Moderkort

RAID-stöd

Ja

Accessories

Cables 2 x SATA 6Gb/s cables 1 x ROG USB2.0 splitter cable 1 x Panel cable Additional Cooling Kit 1 x Thermal pad for M.2 Miscellaneous 1 x ASUS Wi-Fi moving antennas 1 x Cable ties package 1 x M.2 Bracket 1 x M.2 SSD screw package 1 x M.2 Q-Latch package for M.2 backplate 1 x ROG key chain 1 x ROG Strix sticker 1 x ROG Strix thank you card 1 x Rubber Package for M.2 backplate Documentation 1 x User guide

Audio Codec

Realtek ALC4080

Gränssnitt

1 x HDMI, 1 x LAN (2.5Gigabit Ethernet), 1 x ljudingång - mini-jack, 1 x mikrofon - mini-jack, 1 x SPDIF-utgång, 2 x antenn, 2 x USB 2.0, 1 x USB-C 3.2 Gen2x2, 1 x ljudutgång - mini-jack, 4 x USB 3.2 Gen 2, 1 x USB-C 3.2 Gen 2

Produktlinje

ASUS

USB/FireWire

USB 3.2 Gen 1, USB-C 3.2 Gen 2x2, USB-C 3.2 Gen2, USB 3.2 Gen 2

Manageability

WOL by PME, PXE

Paketdetaljer

Låda

Lagringsportar

2 x SATA-600 (RAID), 2 x M.2

News & Updates

Socket AM5

BIOS-egenskaper

UEFI BIOS, ASUS EZ Flash 3

Internminnestyp

DDR5

RAM-kortplatser

2 DIMM-kortplatser

Strömkontakter

8-pin ATX12V-kontakt, 24-pin kontakt för huvudström

Operating System

Windows 11 64-bit, Windows 10 64-bit

Processor-socket

Socket AM5

Special Features

Extreme Engine Digi+ -5K Black Metallic Capacitors ASUS Q-Design - M.2 Q-Latch - Q-DIMM - Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]) - Q-Slot ASUS Thermal Solution - M.2 heatsink backplate - M.2 heatsink - VRM heatsink design ASUS EZ DIY - BIOS FlashBack button - BIOS FlashBack LED - ProCool - Pre-mounted I/O shield - SafeSlot - SafeDIMM AURA Sync - AURA RGB header - Addressable Gen 2 header

Software Features

ROG Exclusive Software - GameFirst VI - ROG CPU-Z - Sonic Studio III + Sonic Studio Virtual Mixer + Sonic Suite Companion - Sonic Radar III - DTS Sound Unbound - Anti-virus software ASUS Exclusive Software Armoury Crate - AIDA64 Extreme (60 days free trial) - AURA Creator - AURA Sync - Fan Xpert 4 - Power Saving - Two-Way AI Noise Cancellation AI Suite 3 - TPU - DIGI+ VRM - Turbo app - PC Cleaner MyAsus WinRAR UEFI BIOS ASUS EZ DIY - ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS UEFI BIOS EZ Mode Dynamic OC Switcher FlexKey

Datalänkprotokoll

IEEE 802.11ac, IEEE 802.11a, Ethernet, Bluetooth 5.2, IEEE 802.11g, IEEE 802.11n, Gigabit Ethernet, Fast Ethernet, 2.5 Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6E), IEEE 802.11b

Hårdvaruegenskaper

CrashFree BIOS 3, FlexKey-knapp, M.2 Q-Latch, ASUS ProCool, ASUS EZ DIY, ASUS Enhanced Memory Profile (AEMP), Q-Slot, ASUS SafeSlot, LANGuard, Automatisk enhets-igenkänning, ASUS TPU (TurboV Processing Unit), Preboot eXecution Environment (PXE), 10 Layer PCB, BIOS FlashBack LED, Q-LED, M.2 kylfläns, 70A Power Stage, ASUS OptiMem II, Förmonterat I/O-skydd, BIOS FlashBack-knapp, Savitech SV3H712-förstärkare, DIY Friendly Design, ASUS Extreme Engine Digi+, ASUS DIGI+ VRM, Q-DIMM, 10K Black Metallic Capacitors, ASUS Aura Sync, ASUS SafeDIMM, 10 + 2 fas kraftdesign, LED-upplysta ljuduttag, VRM-kylelementskonstruktion, Detekteringsteknik för ljudjack

Interna gränssnitt

2 x USB 3.2 Gen 1 - header, 1 x USB 3.2 Gen 2 - header, 1 x ljud - header, 2 x USB 2.0 - header, 1 x högtalare - header

Lagringsgränssnitt

PCIe 4.0 -kontakter: 1 x M.2 - RAID 0 / RAID 1, SATA-600 -kontakter: 2 x 7 pin seriell ATA - RAID 0 / RAID 1, PCIe 5.0 -kontakter: 1 x M.2 - RAID 0 / RAID 1

Medföljande kablar

1 x USB 2.0-delningskabel, 2 x Seriell ATA-kabel

Trådlöst nätverk

Ja

Viloläge/väckning

Wake on PME, Wake on LAN (WOL)

Back Panel I/O Ports

1 x USB 3.2 Gen 2x2 port (1 x USB Type-C) 5 x USB 3.2 Gen 2 ports (4 x Type-A + 1 x USB Type-C with DP Alt mode) 2 x USB 2.0 ports (2 x Type-A) 1 x HDMI port 1 x Wi-Fi Module 1 x Intel 2.5Gb Ethernet port 3 x LED-illuminated audio jacks 1 x Optical S/PDIF out port 1 x BIOS FlashBack button 1 x FlexKey button *The rear panel Lime (Line out) port does not support spatial audio. If you wish to use spatial audio make sure to connect your audio output device to the audio jack on the front panel of your chassis.

Expansionskortplatser

2 x DIMM 288-stift, 2 x M.2 socket (2242/2260/2280 M.2 Key M-plats), 1 x CPU, 1 x PCIe 5.0 x16

RAM-teknik som stöds

DDR5 SDRAM

Standarder som följs

JATE, FCC Part 15 Class B, EU RoHS, EU REACH, VCCI Class B ITE

Inkluderade tillbehör

1 st. M.2-gummipaket, Termisk platta fär M.2 SSD, M.2 Q-Latch, ASUS Wi-Fi rörlig antenn, STRIX-märken, ROG tackkort, Panelkabel, ROG-nyckelring, M.2-skruvpaket, Kabelband, M.2-fäste

Kompatibla processorer

Ryzen

Programvara inkluderad

ROG GameFirst VI, Sonic Studio Virtual Mixer, WinRAR, ROG CPU-Z, Sonic Radar III, ASUS Turbo App, AIDA64 Extreme (60 dagars testperiod), ASUS Fan Xpert 4, ASUS AI Suite III, Armoury Crate, Sonic Suite Companion, Antivirus, ASUS AURA Creator, MyAsus, Sonic Studio III, PC Cleaner

Internal I/O Connectors

Fan and Cooling related 1 x 4-pin CPU Fan header 1 x 4-pin AIO Pump header 1 x 4-pin Chassis Fan header Power related 1 x 24-pin Main Power connector 1 x 8-pin +12V Power connector Storage related 2 x M.2 slots (Key M) 2 x SATA 6Gb/s ports USB 1 x USB 3.2 Gen 2 connector 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports 1 x USB 2.0 headers supports additional 2 USB 2.0 ports Miscellaneous 1 x Addressable Gen 2 header 1 x AURA RGB header 1 x Clear CMOS header 1 x CPU Over Voltage jumper 1 x 12-1 pin Front Panel Audio header (AAFP) 1 x 10-1 pin System Panel header 1 x Speaker header 1 x Thermal Sensor header

RAM-hastighet som stöds

6000 MHz (O.C.), 6400 MHz (O.C.), 6200 MHz (O.C.), 5800 MHz (O.C.), 5000 MHz, 4800 MHz, 5600 MHz (O.C.), 5200 MHz

Stöder Ram Integrity Check

Icke ECC, On-die ECC

Kompatibla processorkommentarer

Stöd för Ryzen 7000 Series

Producentens garanti (månader)

36

USB/FireWire-portkonfiguration (aktiv)

1 x USB-C 3.2 Gen 2x2 + 1 x USB-C 3.2 Gen 2 + 4 x USB 3.2 Gen 2 + 2 x USB 2.0

USB/FireWire-portkonfiguration (sidhuvud)

1 x USB 3.2 Gen 2 + 2 x USB 3.2 Gen 1 + 2 x USB 2.0

RAM som stöds (registrerad eller buffrad)

Ej buffrad
