ROG STRIX B650E-E GAMING WIFI

Övriga specifikationer

EAN

4711081906209

Typ

Ljudkort

USB

Rear USB (Total 12 ports) 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C) 7 x USB 3.2 Gen 2 ports (6 x Type-A + 1 x USB Type-C) 4 x USB 2.0 ports Front USB (Total 7 ports) 1 x USB 3.2 Gen 2 connector (supports USB Type-C) 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports 2 x USB 2.0 headers support additional 4 USB 2.0 ports

BIOS

256 Mb Flash ROM, UEFI AMI BIOS

Ljud

High Definition Audio (8-kanalig)

Modell

ROG Strix B650E-E Gaming WiFi

Chipset

AMD B650E

Lagring

M.2-uttag, Serial ATA-600 (RAID)

BIOS-typ

AMI

Kretstyp

AMD B650

Nätverk

802.11a/b/g/n/ac/ax, Bluetooth 5.2, 2.5 Gigabit Ethernet

Antal M.2

4 st

Egenskaper

AMD EXPO-teknik, Minnesarkitektur med dubbel kanal

Formfaktor

ATX

Produkttyp

Moderkort

RAID-stöd

Ja

Accessories

Cables 2 x SATA 6Gb/s cables Additional Cooling Kit 1 x Thermal pad for M.2 Miscellaneous 1 x ASUS Wi-Fi moving antennas 1 x Cable ties pack 1 x M.2 Q-Latch package 1 x ROG key chain 1 x ROG Strix stickers 1 x ROG Strix thank you card 2 x Rubber Packages for M.2 Documentation 1 x User guide

Audio Codec

Realtek ALC4080

Gränssnitt

1 x SPDIF-utgång, 1 x DisplayPort, 2 x antenn, 1 x ljudutgång - mini-jack, 6 x USB 3.2 Gen 2, 1 x ljudingång - mini-jack, 1 x HDMI, 1 x USB-C 3.2 Gen 2, 1 x USB-C 3.2 Gen2x2, 4 x USB 2.0, 1 x LAN (2.5Gigabit Ethernet), 1 x ljudutgång (center/subwoofer) - mini-jack, 1 x mikrofon - mini-jack, 1 x ljudutgång (bakre) - mini-jack

Produktlinje

ASUS

USB/FireWire

USB 3.2 Gen 2, USB 3.2 Gen 1, USB-C 3.2 Gen2, USB-C 3.2 Gen 2x2

Manageability

WOL by PME, PXE

Lagringsportar

4 x SATA-600 (RAID), 4 x M.2

News & Updates

Socket AM5

BIOS-egenskaper

ASUS EZ Flash 3, UEFI BIOS

Internminnestyp

DDR5

RAID-egenskaper

AMD RAID Xpert2-teknik

RAM-kortplatser

4 DIMM-kortplatser

Strömkontakter

2 x 8-stifts ATX12V-kontakter, 24-pin kontakt för huvudström

Operating System

Windows 10 64-bit, Windows 11 64-bit

Processor-socket

Socket AM5

Special Features

Extreme Engine Digi+ - 5K Black Metallic Capacitors ASUS Q-Design - M.2 Q-Latch - PCIe Slot Q-Release - Q-DIMM - Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]) - Q-Slot ASUS Thermal Solution - M.2 heatsinks - M.2 heatsink backplate - VRM heatsink design ASUS EZ DIY - BIOS FlashBack button - BIOS FlashBack LED - Clear CMOS button - ProCool - Pre-mounted I/O shield - SafeSlot - SafeDIMM Aura Sync - Aura RGB header - Addressable Gen 2 headers

Software Features

ROG Exclusive Software - GameFirst VI - ROG CPU-Z - Sonic Studio III + Sonic Studio Virtual Mixer + Sonic Suite Companion - Sonic Radar III - DTS Sound Unbound - Anti-virus software ASUS Exclusive Software Armoury Crate - AIDA64 Extreme (60 days free trial) - Aura Creator - Aura Sync - Fan Xpert 4 - Power Saving - Two-Way AI Noise Cancellation AI Suite 3 TPU DIGI+ VRM Turbo app PC Cleaner MyAsus WinRAR UEFI BIOS ASUS EZ DIY - ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS UEFI BIOS EZ Mode Dynamic OC Switcher FlexKey

Datalänkprotokoll

IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6E), IEEE 802.11a, Bluetooth 5.2, Ethernet, Gigabit Ethernet, IEEE 802.11b, 2.5 Gigabit Ethernet, IEEE 802.11g, Fast Ethernet

Hårdvaruegenskaper

ASUS ProCool, PCIe Slot Q-Release, Q-LED, BIOS FlashBack LED, Q-Slot, 70A Power Stage, ASUS Q-Design, Water Pump Header, ASUS OptiMem II, ASUS Extreme Engine Digi+, Q-DIMM, 5K Black Metallic Capacitors, ASUS SafeSlot, ASUS Enhanced Memory Profile (AEMP), Automatisk enhets-igenkänning, ASUS SafeDIMM, Q-Code, 16+2 Phase Power Design, Förmonterat I/O-skydd, ASUS Aura Sync, BIOS FlashBack-knapp, Preboot eXecution Environment (PXE), CrashFree BIOS 3, 8 Layer PCB, Savitech SV3H712-förstärkare, DIY Friendly Design, LANGuard, Detekteringsteknik för ljudjack, ASUS EZ DIY, ASUS TPU (TurboV Processing Unit), ASUS DIGI+ VRM, M.2 Q-Latch, Clear CMOS-knapp

Interna gränssnitt

2 x USB 3.2 Gen 1 - header, 4 x USB 2.0 - header, 1 x USB-C 3.2 Gen 2 - header, 1 x Thunderbolt - header, 1 x ljud - header

Lagringsgränssnitt

PCIe 5.0 -kontakter: 2 x M.2 - RAID 0 / RAID 1 / RAID 10, SATA-600 -kontakter: 4 x 7 pin Seriell ATA - RAID 0 / RAID 1 / RAID 10, PCIe 4.0 -kontakter: 2 x M.2 - RAID 0 / RAID 1 / RAID 10

Medföljande kablar

2 x Seriell ATA-kabel

Trådlöst nätverk

Ja

Viloläge/väckning

Wake on LAN (WOL), Wake on PME

Back Panel I/O Ports

1 x USB 3.2 Gen 2x2 port (1 x Type-C) 7 x USB 3.2 Gen 2 ports (6 x Type-A, 1 xUSB Type-C) 4 x USB 2.0 ports 1 x DisplayPort 1 x HDMI port 1 x Wi-Fi Module 1 x Intel 2.5Gb Ethernet port 5 x Audio jacks* 1 x Optical S/PDIF out port 1 x BIOS FlashBack button 1 x Clear CMOS button *The rear panel Line out port does not support spatial audio. If you wish to use spatial audio make sure to connect your audio output device to the audio jack on the front panel of your chassis.

Expansionskortplatser

1 x PCIe 4.0 x16 (x4-läge), 2 x PCIe 5.0 x16, 4 x DIMM 288-stift, 1 x M.2 socket (2230/2242/2260/2280/22110 M.2 Key M-plats), 3 x (2242/2260/2280 M.2 Key M-plats), 1 x CPU

RAM-teknik som stöds

DDR5 SDRAM

Standarder som följs

EU RoHS, VCCI Class B ITE, FCC Part 15 Class B, JATE, DisplayPort 1.4, EU REACH, WEEE

Inkluderade tillbehör

ROG tackkort, ASUS Wi-Fi rörlig antenn, M.2 Q-Latch, ROG-nyckelring, Kabelband, Termisk platta fär M.2 SSD, STRIX-märken, 2 st. M.2-gummipaket

Kompatibla processorer

Ryzen

Programvara inkluderad

ROG CPU-Z, Sonic Suite Companion, ASUS AI Suite III, Sonic Radar III, Sonic Studio Virtual Mixer, ASUS Fan Xpert 4, PC Cleaner, AIDA64 Extreme (60 dagars testperiod), Sonic Studio III, ASUS AURA Creator, MyAsus, ASUS Turbo App, ROG GameFirst VI, Armoury Crate, WinRAR

Internal I/O Connectors

Fan and Cooling related 1 x 4-pin CPU Fan header 1 x 4-pin CPU OPT Fan header 1 x 4-pin AIO Pump header 5 x 4-pin Chassis Fan headers Power related 1 x 24-pin Main Power connector 2 x 8-pin +12V Power connector Storage related 4 x M.2 slots (Key M) 4 x SATA 6Gb/s ports USB 1 x USB 3.2 Gen 2 connector (supports USB Type-C) 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports 2 x USB 2.0 headers support additional 4 USB 2.0 ports Miscellaneous 3 x Addressable Gen 2 headers 1 x Aura RGB header 1 x CPU Over Voltage jumper 1 x Front Panel Audio header (AAFP) 1 x 20-3 pin System Panel header with Chassis intrude function 1 x Thermal Sensor header 1 x Thunderbolt (USB4) header

RAM-hastighet som stöds

6400 MHz (O.C.), 5000 MHz, 6200 MHz (O.C.), 5800 MHz (O.C.), 5200 MHz, 6000 MHz (O.C.), 4800 MHz, 5600 MHz (O.C.)

Stöder Ram Integrity Check

On-die ECC, Icke ECC

Kompatibla processorkommentarer

Stöd för Ryzen 7000 Series

Producentens garanti (månader)

36

USB/FireWire-portkonfiguration (aktiv)

1 x USB-C 3.2 Gen 2x2 + 1 x USB-C 3.2 Gen 2 + 6 x USB 3.2 Gen 2 + 4 x USB 2.0

USB/FireWire-portkonfiguration (sidhuvud)

1 x USB-C 3.2 Gen 2 + 2 x USB 3.2 Gen 1 + 4 x USB 2.0

RAM som stöds (registrerad eller buffrad)

Ej buffrad
