Effekt

750 W

ATX-version

ATX 3.0

Dimensioner

180 × 150 × 86 mm

Effektivitet

80+ Gold

Formfaktor

ATX

Skydd

OPP/OVP/UVP/SCP/OCP/OTP

EPS-kontakter

2

SATA-kontakter

5

12VHPWR-kontakter

1

PCIe 8-pin-kontakter

3

Övriga specifikationer

MTBF

>120,000 hrs @ 25°C

Weight

2.689 kg (single PSU)

PFC Type

Active PFC

AURA SYNC

ARGB

Maximum Load

22A 22A 62.5A 0.3A 3A

Combined Load

120W 120W 750W 3.6W 15W

0dB Fan Button

Yes. When the Button is ON, the fan will only spin up when the system reaches a certain load. When the Button is OFF, the fan will continuously spin at all load levels.

0dB Technology

Supported. The fan shuts off entirely when the PSU is under certain load

AC Input Range

100-240Vac

Package Contents

Power Cord x 1 Motherboard Power Cable x 1 (600mm) CPU Cable x 2 (650mm) PCI-E Gen 5 16-pin Cable x 1 (675mm) PCI-E 1-to-1 Cable x 1 (675mm) PCI-E (16-pin to 8-pin-8-pin) Cable x 1 (675mm) SATA 1-to-2 Cable x 1 (400+120mm) SATA 1-to-3 Cable x 1 (400+120+120mm) Peripheral 1-to-4 Cable x 1 (400+150+150+150mm) Addressable RGB Cable x 1 (800mm) User Manual x 1

DC Output Voltage

+3.3V +5V +12V -12V +5Vsb

Hazardous Materials

ROHS

Cybenetics Noise Level Certification

A++
