Effekt

650 W

Dimensioner

16 × 15 × 8.6 Centimeter

Effektivitet

80+ Gold

Skydd

OPP/OVP/UVP/SCP/OCP/OTP

EPS-kontakter

2

SATA-kontakter

8

PCIe 8-pin-kontakter

4

Övriga specifikationer

MTBF

>120,000 hrs @ 25°C

Fan Size

135mm

PFC Type

Active PFC

Maximum Load

20A 20A 54A 0.3A 3A

RGB Connector

NA

0dB Technology

Supported. The fan shuts off entirely when the PSU is under certain load

AC Input Range

100-240Vac

Package Contents

Power Cord x 1 Motherboard Power cable x 1 (610mm) CPU Cable x 2 (1000mm) PCIE 1-to-2 Cable x2 (675+75mm) SATA 1-to-4 Cable x1 (410+150+150+150mm) SATA 1-to-4 Cable x1 (450+120+120+120mm) Peripheral 1-to-3 Cable x1 (450+120+120mm) Join the ROG badge x 2 ROG logo magnet x 1 ROG label x 3 *MB/ CPU/ PCI-E cables come with embedded capacitors in the middle.

DC Output Voltage

+3.3V +5V +12V -12V +5Vsb

Hazardous Materials

ROHS

Cybenetics Noise Level Certification

NA
