Mesh-stöd

AiMesh

Övriga specifikationer

LAN

DHCP Server, IGMP Snooping, IPTV, LAN Link Aggregation, Manually Assign IP Address, Wake on LAN (WOL)

VPN

VPN Client L2TP, VPN Client Open VPN, VPN Client PPTP, VPN Client WireGuard, VPN Server IPSec, VPN Server Open VPN, VPN Server PPTP, VPN Server WireGuard, VPN Fusion

WAN

Dual WAN, 3G / 4G LTE Dongle, 4G / 5G Auto Mobile Tethering, Port Forwarding, • Maximum Port Forwarding Rule : 64, Port Triggering, • Maximum Port Triggering Rule : 32, DMZ, DDNS, NAT Passthrough : PPTP, L2TP, IPSec, RTSP, H.323, SIP Passthrough, PPPoE relay

Spel

Game Boost / Acceleration, Game Radar, WTFast, ROG_First, OpenNAT (Game Profile), Gaming Port

Knapp

WPS Button Reset Button Power Switch

Minne

256MB Flash 512MB DDR4 RAM

AiMesh

AiMesh, • Primary AiMesh Router, • AiMesh Node

Antenn

Internal antenna x 9

Design

Black Moonlight White

Portar

1 x 2.5 Gigabit WAN Port 3 x Gigabit LAN Ports 1 x USB 3.2 Gen 1x1 Port

Security

WiFi Encryption : WPA3 Personal, WPA2 Personal, WPA Personal, WPA Enterprise, WPA2 Enterprise, Open System, WPS, Let's Encrypt, DNS-over-TLS, SSH, Security Scan, Firewall, • Maximum Firewall Keyword Filter : Max 64 rules, • Maximum Firewall Network Service Filter : Max 32 rules, • Maximum Firewall URL Filter : Max 64 rules

Processor

1.7GHz tri-core processor

Trådlös

MU-MIMO, UTF-8 SSID, WiFi MAC Address Filter, • Maximum MAC Filters : 64, Wireless Scheduler, Wi-Fi Radar, Airtime Fairness, RADIUS Client, Universal Beamforming, Explicit Beamforming

Modellnamn

GT6(W-2-PK)

LED-visning

Power x 1

USB-program

4G / 5G Auto Mobile Tethering, File System : HFS+, NTFS, vFAT, ext2, ext3, ext4, Safely Remove Disk, AiCloud, Download Master, AiDisk, Media Server, Time Machine, Samba Server, FTP Server, Shared Folder Privileges

AiProtection

AiProtection Pro, • Router Security Assessment, • Malicious Site Blocking, • Two-Way IPS, • Infected Device Prevention and Blocking

Wi-Fi-teknik

OFDMA (Orthogonal Frequency Division Multiple Access) Beamforming: standard-based and universal 1024-QAM high data rate 20/40/80/160 MHz bandwidth * The 160MHz bandwidth may be unavailable in the 5GHz band in some regions / countries due to regulatory restrictions.

Datahastighet

2.4GHz AX: 2x2 (Tx/Rx) 1024 QAM 20/40MHz, up to 574Mbps\n5G-1Hz AX: 4x4 (Tx/Rx) 1024 QAM 20/40/80/160MHz, up to 4804Mbps\n5G-2Hz AX: 4x4 (Tx/Rx) 1024 QAM 20/40/80/160MHz, up to 4804Mbps

Guest Network

"The Guest Network provides Internet connection for guests but restricts access to your local network.", Guest Network Connection time limit

Administration

Configuration Backup and Restore, Diagnosis Tools, Feedback System, System Log, New Device Connect Notification, Login Captcha, Connection Diagnosis, Auto Firmware Update

Driftsfrekvens

2.4G Hz 5 GHz-1 5 GHz-2

Operating Mode

Wireless router mode Access point mode Aimesh mode

Produktsegment

AX10000 ultimate AX performance

Skicka/Ta emot

2.4GHz 2x2\n5GHz-1 4x4\n5GHz-2 4x4

Produktvikt (g)

880 g

Trafikhantering

Adaptive QoS, • Bandwidth Monitor, • Bandwidth Limiter, Traditional QoS, Traffic Monitor, • Real-time Traffic Monitor, • Wired Traffic Monitor, • Wireless Traffic Monitor, Traffic Analyzer, • Traffic Analysis Period : Daily, Weekly, Monthly, • Website History

Nätverksstandard

WiFi 6 (802.11ax)\nIPv4\nIPv6\nBackwards compatible with 802.11a/b/g/n/ac Wi-Fi

Paketets inehåll

ROG Rapture GT6 RJ-45 Cable Power Adapter Quick Start Guide Warranty Card

Föräldrakontroll

"Allow you to block access to unwanted websites and apps.", Parental Control Customized Internet Schedule

Product Dimensions

172.3 x 78.1 x 176.75 mm

Strömförsörjning

AC Input : 110V~240V(50~60Hz) DC Output : 19 V with max. 2.37 A current / 19.5 V with max. 2.31 A current
