Effekt

1200 W

ATX-version

ATX 3.1

Dimensioner

125 × 125 × 63.5 mm

Effektivitet

80+ Titanium

Formfaktor

SFX-L

Skydd

OPP/OVP/UVP/SCP/OCP/OTP

EPS-kontakter

2

SATA-kontakter

6

12VHPWR-kontakter

2

PCIe 8-pin-kontakter

4

Övriga specifikationer

MTBF

>120,000 hrs @ 25°C

Weight

2.15 kg (single PSU)

PFC Type

Active PFC

AURA SYNC

ARGB

Maximum Load

20A 20A 100A 0.8A 3A

Combined Load

110W 110W 1200W 9.6W 15W

0dB Technology

Supported. The fan shuts off entirely when the PSU is under certain load

AC Input Range

100-240Vac

Package Contents

Power Cord x 1 Motherboard Power Cable x 1 (450mm) CPU Cable x 2 (550mm) PCI-E Gen 5.1 16-pin Cable x 2 (450mm) PCI-E (16-pin to 8-pin-8-pin) Cable x 2 (450mm) SATA 1-to-3 Cable x 2 (300+200+100mm) Peripheral 1-to-4 Cable x 1 (300+100+100+100mm) Addressable RGB Cable x 1 (800mm) User Manual x 1 ATX to SFX adapter bracket x 1

DC Output Voltage

+3.3V +5V +12V -12V +5Vsb

Hazardous Materials

ROHS

Cybenetics Noise Level Certification

S++
