WiFi

WiFi 7

Sockel

LGA 1851

Chipset

Intel Z890

M.2-platser

3

Ethernet

5 Gigabit

Max minne

128 GB

PCIe-platser

CPU: / 1 x PCIe 5.0 x16 Slot (PCIE1), supports x16 mode*Chipset: / 1 x Vertical M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module / 15μ Gold Contact in VGA PCIe Slot (PCIE1)* PCIE1 supports PCIe riser cards to extend one x16 slot to x8/x8 or x8/x4/x4 slots. Supports NVMe SSD as boot disks

SATA-portar

2

Ljudkodek

Realtek ALC4082

Dimensioner

170 × 170mm

Formfaktor

Mini-ITX

Minnestyp

DDR5

Minnesplatser

2

Displayutgångar

Intel Xe LPG Graphics Architecture / 1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz / 2 x Intel Thunderbolt 4, support HDCP 2.3 and max. resolution up to 8K 60Hz / 5K 120Hz** Intel UHD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated. Supports two 4K displays or one 8K display Only the CPU's embedded graphics can be displayed through Thunderbolt ports. If you want to display to a Thunderbolt monitor, please use CPU models with embedded graphics.

Max minneshastighet

9866 MHz

Övriga specifikationer

OS

Microsoft Windows 11 64-bit

USB

CPU: / 2 x Thunderbolt 4/USB4 Type-C (Rear)Chipset: / 1 x USB 3.2 Gen2x2 Type-C (Front) / 6 x USB 3.2 Gen2 Type-A (Rear) / 2 x USB 3.2 Gen1 (Front) / 2 x USB 2.0 (Front)* All USB ports support ESD Protection

BIOS

256Mb AMI UEFI Legal BIOS with GUI support

RAID

Supports RAID 0 and RAID 1 for SATA storage devices / Supports RAID 0, RAID 1, RAID 5 and RAID 10 for M.2 NVMe storage devices* Requires additional M.2 NVMe expansion cards to support RAID 10

Connector

1 x Thermistor Cable Header / 2 x Addressable LED Headers* / 1 x CPU Fan Connector (4-pin) (Smart Fan Speed Control)** / 1 x Chassis Fan Connector (4-pin) (Smart Fan Speed Control)** / 1 x AIO Pump Fan Connector (4-pin) (Smart Fan Speed Control)*** / 1 x 24 pin ATX Power Connector (Hi-Density Power Connector) / 1 x 8 pin 12V Power Connector (Hi-Density Power Connector) / 1 x Front Panel Audio Connector (15μ Gold Audio Connector) / 1 x USB 2.0 Headers (Supports 2 USB 2.0 ports) / 1 x USB 3.2 Gen1 Headers (Supports 2 USB 3.2 Gen1 ports) / 1 x Front Panel Type C USB 3.2 Gen2x2 Header (20 Gb/s)* Support in total up to 5V/3A, 15W LED Strip** CPU_FAN and CHA_FAN1 support the fan power up to 2A (24W).*** AIO_PUMP supports the fan power up to 3A (36W). AIO_PUMP can auto detect if 3-pin or 4-pin fan is in use.

Accessories

2 x SATA Data Cables / 1 x ASRock WiFi 2.4/5/6 GHz Antenna / 1 x ARGB Splitter Cable / 1 x Thermistor Cable / 3 x Screws for M.2 Sockets

Certifications

FCC, CE / ErP/EuP ready (ErP/EuP ready power supply is required)

Rear Panel I/O

2 x Antenna Ports / 1 x HDMI Port / 2 x Thunderbolt 4/USB4 Type-C Ports (40 Gb/s)* / 1 x Optical SPDIF Out Port / 6 x USB 3.2 Gen2 Type-A Port (10 Gb/s) / 1 x RJ-45 LAN Port / 1 x BIOS Flashback Button / 1 x Line Out Jack (Gold Audio Jack) / 1 x Microphone Input Jack (Gold Audio Jack)* Supports USB PD 3.0 up to 5V@3A (15W) charging

Unique Feature

Superb Productivity / PCIe Gen5 (Graphics, M.2) / Dual Channel DDR5 / Thunderbolt 4/USB4 Type-C Ports (40 Gb/s)Rock-Solid Durability / Server-Grade Low-Loss PCB / 12+1+1+1+1 Power Phase, 110A SPS for VCore with Enlarged Heatsink Armor / Memory OC Shield / Flexible Integrated I/O Shield / 20K Long-lasting Black Caps (high quality and conductive polymer capacitors)Ultrafast Gaming / 5G LAN, 802.11be Wi-Fi 7 ModuleEZ Update / BIOS Flashback Button / ASRock Auto Driver InstallerEZ Troubleshooter / ASRock Post Status Checker

Software and UEFI

Software / ASRock Motherboard Utility (Phantom Gaming Tuning) / ASRock Phantom Gaming LAN Software / ASRock Polychrome SYNC*UEFI / ASRock EZ Mode / ASRock Full HD UEFI / ASRock My Favorites in UEFI / ASRock Auto Driver Installer / ASRock Instant Flash*These utilities can be downloaded from ASRock Live Update & APP Shop.
