WiFi

WiFi 6

Sockel

LGA 1700

Chipset

Intel Z790

M.2-platser

2

Ethernet

2.5 Gigabit

Max minne

128 GB

PCIe-platser

CPU: / 1 x PCIe 5.0 x16 Slot (PCIE1), supports x16 mode*Chipset: / 1 x Vertical M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module and Intel CNVio/CNVio2 (Integrated WiFi/BT)*Supports PCIe riser cards to extend one x16 slot to two x8 slotsSupports NVMe SSD as boot disks

SATA-portar

4

Ljudkodek

Realtek ALC897

Dimensioner

170 × 170mm

Formfaktor

Mini-ITX

Minnestyp

DDR5

Minnesplatser

2

Displayutgångar

Intel Xe Graphics Architecture (Gen 12) / 1 x eDP 1.4, supports max. resolution up to Full HD 60Hz / 1 x HDMI 2.1 TMDS Compatible, supports HDCP 2.3 and max. resolution up to 4K 60Hz / 1 x DisplayPort 1.4 with DSC (compressed), supports HDCP 2.3 and max. resolution up to 8K 60Hz / 5K 120Hz*Intel UHD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated.

Max minneshastighet

7000 MHz

Övriga specifikationer

OS

Microsoft Windows 10 64-bit / 11 64-bit*Windows 10 only supports version 21H2 or later

USB

1 x USB 3.2 Gen2x2 Type-C (Rear) / 1 x USB 3.2 Gen2x2 Type-C (Front) / 4 x USB 3.2 Gen2 Type-A (Rear) / 2 x USB 3.2 Gen1 (Front) / 3 x USB 2.0 (1 Rear, 2 Front)*All USB ports support ESD Protection

BIOS

128Mb AMI UEFI Legal BIOS with GUI support

RAID

Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices / Supports RAID 0, RAID 1 and RAID 5 for M.2 NVMe storage devices** Requires additional M.2 NVMe expansion cards to support RAID 5

Connector

1 x eDP Signal Connector / 1 x RGB LED Header* / 1 x Addressable LED Header** / 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)*** / 2 x Chassis Fan Connectors (4-pin)**** / 1 x 24 pin ATX Power Connector / 1 x 8 pin 12V Power Connector (Hi-Density Power Connector) / 1 x Front Panel Audio Connector / 1 x USB 2.0 Header (Supports 2 USB 2.0 ports) / 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) / 1 x Front Panel Type C USB 3.2 Gen2x2 Header (20 Gb/s)******Supports in total up to 12V/3A, 36W LED Strip**Supports in total up to 5V/3A, 15W LED Strip***CPU_FAN1/WP supports the fan power up to 2A (24W).CPU_FAN1/WP can auto detect if 3-pin or 4-pin fan is in use.****CHA_FAN1~2 support the fan power up to 1A (12W).*****Actual speed depends on USB devices and extension cable in the chassis.

Accessories

1 x User Manual / 1 x I/O Shield / 2 x SATA Data Cables / 2 x ASRock WiFi 2.4/5/6 GHz Antennas / 2 x Screws for M.2 Sockets

Certifications

FCC, CE / ErP/EuP ready (ErP/EuP ready power supply is required)

Rear Panel I/O

2 x Antenna Ports / 1 x HDMI Port / 1 x DisplayPort 1.4 / 1 x Optical SPDIF Out Port / 4 x USB 3.2 Gen2 Type-A Ports (10 Gb/s) / 1 x USB 3.2 Gen2x2 Type-C Port (20 Gb/s) / 1 x USB 2.0 Port / 2 x RJ-45 LAN Ports / 1 x Line Out Jack (Gold Audio Jack) / 1 x Microphone Input Jack (Gold Audio Jack)

Unique Feature

Superb Productivity / PCIe Gen5 (Graphic) / Dual Channel DDR5Rock-Solid Durability / 7+1+1 Power Phase, 50A Dr.MOS for VCore+GT / Nichicon 12K Black Caps (100% Japan made high quality conductive polymer capacitors)Ultrafast Connectivity / 2.5G LAN, 802.11ax Wi-Fi 6E ModuleEZ Update / ASRock Auto Driver Installer

Software and UEFI

Software / ASRock Motherboard Utility (A-Tuning) / ASRock Polychrome SYNCUEFI / ASRock EZ Mode / ASRock Full HD UEFI / ASRock My Favorites in UEFI / ASRock Auto Driver Installer / ASRock Instant Flash / ASRock Easy RAID Installer*These utilities can be downloaded from ASRock Live Update & APP Shop.
