WiFi

WiFi 6

Sockel

LGA 1700

Chipset

Intel Z790

M.2-platser

3

Ethernet

2.5 Gigabit

Max minne

128 GB

PCIe-platser

CPU: / 1 x PCIe 5.0 x16 Slot (PCIE1), supports x16 mode*Chipset: / 1 x Vertical M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module and Intel CNVio/CNVio2 (Integrated WiFi/BT) / 15μ Gold Contact in VGA PCIe Slot (PCIE1)*Supports PCIe riser cards to extend one x16 slot to two x8 slotsSupports NVMe SSD as boot disks

SATA-portar

3

Ljudkodek

Realtek ALC4082

Dimensioner

170 × 170mm

Formfaktor

Mini-ITX

Minnestyp

DDR5

Minnesplatser

2

Displayutgångar

Intel Xe Graphics Architecture (Gen 12) / 1 x HDMI 2.1 TMDS Compatible, supports HDCP 2.3 and max. resolution up to 4K 60Hz / 1 x DisplayPort 1.4 with DSC (compressed), supports HDCP 2.3 and max. resolution up to 8K 60Hz / 5K 120Hz / 2 x Intel Thunderbolt 4, supports HDCP 2.3 and max. resolution up to 8K 60Hz***Intel UHD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated.**Supports two 4K displays or one 8K displayOnly the CPU's embedded graphics can be displayed through Thunderbolt ports. If you want to display to a Thunderbolt monitor, please use CPU models with embedded graphics.Thunderbolt graphics output may not be compatible with certain Type-C monitors. Please use graphics card outputs instead.

Max minneshastighet

7000 MHz

Övriga specifikationer

OS

Microsoft Windows 10 64-bit / 11 64-bit*Windows 10 only supports version 21H2 or later

USB

2 x USB4 Thunderbolt 4 Type-C (Rear) / 1 x USB 3.2 Gen2x2 Type-C (Front) / 6 x USB 3.2 Gen2 Type-A (Rear) / 2 x USB 3.2 Gen1 (Front) / 2 x USB 2.0 (Front)* All USB ports support ESD Protection

BIOS

256Mb AMI UEFI Legal BIOS with GUI support

RAID

Supports RAID 0, RAID 1 and RAID 5 for SATA storage devices / Supports RAID 0, RAID 1 and RAID 5 for M.2 NVMe storage devices

Connector

1 x RGB LED Header* / 1 x Addressable LED Header** / 1 x CPU Fan Connector (4-pin)*** / 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)**** / 1 x Chassis Fan Connector (4-pin)***** / 1 x 24 pin ATX Power Connector (Hi-Density Power Connector) / 1 x 8 pin 12V Power Connector (Hi-Density Power Connector) / 1 x Front Panel Audio Connector (15μ Gold Audio Connector) / 1 x USB 2.0 Header (Supports 2 USB 2.0 ports) / 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) / 1 x Front Panel Type C USB 3.2 Gen2x2 Header (20 Gb/s) / 1 x Clear CMOS Button*Supports in total up to 12V/3A, 36W LED Strip**Supports in total up to 5V/3A, 15W LED Strip***CPU_FAN1 supports the fan power up to 1A (12W).****CPU_FAN2/WP supports the fan power up to 2A (24W).****CPU_FAN2/WP can auto detect if 3-pin or 4-pin fan is in use.*****CHA_FAN1 supports the fan power up to 1A (12W).

Accessories

1 x User Manual / 2 x SATA Data Cables / 1 x ASRock WiFi 2.4/5/6 GHz Antenna / 2 x Thermal Pads for M.2 SSD / 3 x Screws for M.2 Sockets

Certifications

FCC, CE / ErP/EuP ready (ErP/EuP ready power supply is required)

Rear Panel I/O

2 x Antenna Ports / 1 x HDMI Port / 1 x DisplayPort 1.4 / 1 x Optical SPDIF Out Port / 2 x USB4 Thunderbolt 4 Type-C Ports (40 Gb/s for USB4 protocol; 40Gb/s for Thunderbolt protocol)* / 6 x USB 3.2 Gen2 Type-A Ports (10 Gb/s) / 1 x RJ-45 LAN Port / 1 x Line Out Jack (Gold Audio Jack) / 1 x Microphone Input Jack (Gold Audio Jack)*Supports USB PD 3.0 up to 9V@3A (27W) / 5V@3A (15W) charging

Unique Feature

Superb Productivity / PCIe Gen5 (Graphic) / Dual Channel DDR5 / USB4 Thunderbolt 4 Type-C Ports (40 Gb/s)Rock-Solid Durability / 10+1+1 Power Phase, 105A SPS for VCore with Enlarged Heatsink Armor / Flexible Integrated I/O Shield / Nichicon 12K Black Caps (100% Japan made high quality conductive polymer capacitors)Ultrafast Connectivity / Killer 2.5G LAN, Killer, 802.11ax Wi-Fi 6E Module / Killer DoubleShot ProEZ Update / ASRock Auto Driver InstallerEZ Troubleshooter / ASRock Post Status Checker

Software and UEFI

Software / ASRock Motherboard Utility (Phantom Gaming Tuning) / Killer Control Center / ASRock Polychrome SYNC*UEFI / ASRock EZ Mode / ASRock Full HD UEFI / ASRock My Favorites in UEFI / ASRock Auto Driver Installer / ASRock Instant Flash / ASRock Easy RAID Installer*These utilities can be downloaded from ASRock Live Update & APP Shop.
