WiFi

WiFi 6

Sockel

LGA 1700

Chipset

Intel Z690

M.2-platser

2

Ethernet

2.5 Gigabit

Max minne

192 GB

PCIe-platser

CPU: / 2 x PCIe 5.0 x16 Slots (PCIE1 and PCIE2), support x16 or x8/x8 modes*Chipset: / 1 x PCIe 4.0 x16 Slot (PCIE4), supports x4 mode* / 1 x PCIe 3.0 x1 Slot (PCIE3)* / 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module and Intel CNVi (Integrated WiFi/BT) / Supports AMD CrossFire / 15μ Gold Contact in VGA PCIe Slots (PCIE1 and PCIE2)*Supports NVMe SSD as boot disks

SATA-portar

6

Ljudkodek

Realtek ALC1220

Dimensioner

305 × 244mm

Formfaktor

ATX

Minnestyp

DDR5

Minnesplatser

4

Displayutgångar

Intel Xe Graphics Architecture (Gen 12) / Three graphics output options: 1 x HDMI and 2 x Intel Thunderbolt 4 / Supports Triple Monitor / Supports Intel Thunderbolt 4 with max. resolution up to 8K (7680x4320) @ 60Hz** / Supports HDMI 2.1 TMDS Compatible with max. resolution up to 4K x 2K (4096x2160) @ 60Hz / Supports HDCP 2.3 with HDMI 2.1 TMDS Compatible Port and Intel Thunderbolt 4 Ports*Intel UHD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated.**Supports two 4K displays or one 8K display

Max minneshastighet

6400 MHz

Övriga specifikationer

OS

Microsoft Windows 10 64-bit / 11 64-bit

BIOS

256Mb AMI UEFI Legal BIOS with multilingual GUI support / ACPI 6.0 Compliant wake up events / SMBIOS 2.7 Support / CPU Core/Cache, CPU GT, DRAM, VCCIN_AUX, +1.8V PROC, +1.05V PROC, +0.82V PCH, +1.05V PCH Voltage Multi-adjustment

RAID

Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices / Supports RAID 0, RAID 1 and RAID 5 for M.2 NVMe storage devices

Connector

1 x SPI TPM Header / 1 x Power LED and Speaker Header / 1 x RGB LED Header* / 3 x Addressable LED Headers** / 1 x CPU Fan Connector (4-pin)*** / 2 x CPU/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)**** / 4 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)***** / 1 x VRM/Water Pump Fan Connector (4-pin)****** / 1 x 24 pin ATX Power Connector (Hi-Density Power Connector) / 2 x 8 pin 12V Power Connectors (Hi-Density Power Connector) / 1 x Front Panel Audio Connector (15μ Gold Audio Connector) / 2 x USB 2.0 Headers (Support 3 USB 2.0 ports) (Supports ESD Protection) / 1 x Independent USB 3.2 Gen1 Type-A Connector / 2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports) (ASMedia ASM1074 hub) (Supports ESD Protection) / 1 x Front Panel Type C USB 3.2 Gen2x2 Header (20 Gb/s) (Supports ESD Protection) / 1 x Clear CMOS Button / 1 x Dr. Debug with LED / 1 x Power Button with LED / 1 x Reset Button with LED*Supports in total up to 12V/3A, 36W LED Strip**Support in total up to 5V/3A, 15W LED Strip***The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power.****CPU_FAN2/WP_3A supports the water cooler fan of maximum 3A (36W) fan power.CPU_FAN3/WP supports the water cooler fan of maximum 2A (24W) fan power.*****The Chassis/Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power.******The VRM/Water Pump Fan Connector supports the VRM fan of maximum 2A (24W) fan power.CPU_FAN2/WP_3A, CPU_FAN3/WP, VRM_FAN1/WP, CHA_FAN1~4/WP can auto detect if 3-pin or 4-pin fan is in use.

Accessories

4 x SATA Data Cables / 1 x Graphics Card Holder / 1 x Wireless Dongle USB Bracket / 1 x 3010 Cooling Fan with Bracket and Screw Package / 1 x 4010 Cooling Fan Bracket and Screw Package / 1 x ASRock WiFi 2.4/5/6 GHz Antenna / 3 x Screws for M.2 Sockets / 1 x Standoff for M.2 Socket

Certifications

FCC, CE / ErP/EuP ready (ErP/EuP ready power supply is required) / CEC Tier II ready

Rear Panel I/O

2 x Antenna Ports / 1 x HDMI Port / 1 x Optical SPDIF Out Port / 2 x USB 3.2 Gen2 Type-A Ports (10 Gb/s) (ReDriver) (Supports ESD Protection) / 2 x USB 4.0 Thunderbolt 4 Type-C Ports (40 Gb/s for USB 4.0 protocol; 40Gb/s for Thunderbolt protocol) (Supports ESD Protection)* / 4 x USB 3.2 Gen1 Type-A Ports (Supports ESD Protection)** / 2 x RJ-45 LAN Ports with LED (ACT/LINK LED and SPEED LED) / 1 x BIOS Flashback Button / HD Audio Jacks: Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone (Gold Audio Jacks with LED)*Supports USB PD 3.0 up to 9V@3A (27W) / 5V@3A (15W) charging**USB3_2, USB3_3 and USB3_4 are from Intel Z690; USB3_1 is from ASMedia ASM3042.USB3_1_2 are the Lightning Gaming Ports.Ultra USB Power is supported on USB3_3 port.ACPI wake-up function is not supported on USB3_3 port.

Unique Feature

ASRock USB 4.0 / ASRock USB 4.0 Thunderbolt 4 Type-C Port (40 Gb/s for USB 4.0 protocol; 40Gb/s for Thunderbolt protocol)ASRock USB 3.2 Gen2 / ASRock Front Panel Type-C USB 3.2 Gen2x2 Header (20 Gb/s) / ASRock USB 3.2 Gen2 Type-A Port (10 Gb/s)ASRock Super Alloy / XXL Aluminum Alloy Heatsink / Premium Power Choke / 105A SPS (Smart Power Stage) / Premium Memory Alloy Choke (Reduces 70% core loss compared to iron power choke) / Nichicon 12K Black Caps (100% Japan made high quality conductive polymer capacitors) / I/O Armor / Matte Black PCB / High Density Glass Fabric PCB / 8 Layer PCB / 2oz Copper PCBServer-Grade Low-Loss PCBKiller 2.5G LAN802.11ax Wi-Fi 6EKiller DoubleShot ProASRock Auto Driver InstallerASRock Steel SlotsASRock Full Coverage M.2 HeatsinkASRock Hyper M.2 (PCIe Gen4x4)ASRock Ultra USB PowerASRock Full Spike Protection (for all USB, Audio, LAN Ports)ASRock Live Update & APP Shop

Hardware Monitor

Fan Tachometer: CPU, CPU/Water Pump, Chassis/Water Pump, VRM/Water Pump, MOS Fans / Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, CPU/Water Pump, Chassis/Water Pump, VRM/Water Pump, MOS Fans / Fan Multi-Speed Control: CPU, CPU/Water Pump, Chassis/Water Pump, VRM/Water Pump, MOS Fans / Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, +0.82V PCH, +1.05V PCH, +1.05V PROC, DRAM, VCCIN_AUX, VCCSA

Software and UEFI

Software / ASRock Motherboard Utility (A-Tuning) / Killer Control Center / ASRock Polychrome SYNC*UEFI / ASRock EZ Mode / ASRock Full HD UEFI / ASRock My Favorites in UEFI / ASRock Auto Driver Installer / ASRock Instant Flash / ASRock Easy RAID Installer*These utilities can be downloaded from ASRock Live Update & APP Shop.
