WiFi

WiFi 6

Sockel

AM5

Chipset

AMD X670

M.2-platser

4

Ethernet

2.5 Gigabit

Max minne

256 GB

PCIe-platser

CPU: / 2 x PCIe 5.0 x16 Slots (PCIE1 and PCIE2), support x16 or x8/x8 modes*Chipset: / 1 x Vertical M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module / Supports AMD CrossFire / 15μ Gold Contact in VGA PCIe Slot (PCIE1)*Supports NVMe SSD as boot disks

SATA-portar

4

Ljudkodek

Realtek ALC4082

Dimensioner

305 × 267mm

Formfaktor

EATX

Minnestyp

DDR5

Minnesplatser

4

Displayutgångar

Integrated AMD RDNA graphics (Actual support may vary by CPU) / 1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz / 2 x USB4, support HDCP 2.3 and max. resolution up to 8K 60Hz**Only the CPU's embedded graphics can be displayed through USB4 ports. If you want to display to a Type-C monitor, please use AM5 Ryzen 7000 processors with embedded graphics.

Max minneshastighet

7800 MHz

Övriga specifikationer

OS

Microsoft Windows 10 64-bit / 11 64-bit

USB

2 x USB4 Type-C (Rear) / 1 x USB 3.2 Gen2x2 Type-C (Front) / 5 x USB 3.2 Gen2 Type-A (Rear) / 7 x USB 3.2 Gen1 (3 Rear, 4 Front) / 4 x USB 2.0 (Front)*All USB ports support ESD Protection

BIOS

256Mb AMI UEFI Legal BIOS with GUI support

RAID

Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices / Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe storage devices

Connector

1 x Power LED and Speaker Header / 1 x RGB LED Header* / 3 x Addressable LED Headers** / 1 x CPU Fan Connector (4-pin)*** / 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)**** / 6 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)***** / 1 x 24 pin ATX Power Connector (Hi-Density Power Connector) / 2 x 8 pin 12V Power Connectors (Hi-Density Power Connector) / 1 x Front Panel Audio Connector (15μ Gold Audio Connector) / 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) / 2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports) / 1 x Front Panel Type C USB 3.2 Gen2x2 Header (20 Gb/s) / 1 x Dr. Debug with LED / 1 x Power Button with LED / 1 x Reset Button with LED*Supports in total up to 12V/3A, 36W LED Strip**Support in total up to 5V/3A, 15W LED Strip***CPU_FAN1 supports the fan power up to 1A (12W).****CPU_FAN2/WP_3A supports the fan power up to 3A (36W).*****CHA_FAN1~6/WP support the fan power up to 2A (24W).CPU_FAN2/WP_3A and CHA_FAN1~6/WP can auto detect if 3-pin or 4-pin fan is in use.

Accessories

1 x User Manual / 4 x SATA Data Cables / 1 x Wireless Dongle USB Bracket / 1 x Blazing M.2 Gen5 Fan Heatsink / 1 x ASRock WiFi 2.4/5/6 GHz Antenna / 4 x Screws for M.2 Sockets / 1 x Standoff for M.2 Socket

Certifications

FCC, CE / ErP/EuP ready (ErP/EuP ready power supply is required) / CEC Tier II ready

Rear Panel I/O

2 x Antenna Ports / 1 x HDMI Port / 1 x Optical SPDIF Out Port / 2 x USB4 Type-C Ports (40 Gb/s)* / 5 x USB 3.2 Gen2 Type-A Ports (10 Gb/s) (ReDriver) (USB32_12 are Lightning Gaming Ports. USB32_3 supports Ultra USB Power.)** / 3 x USB 3.2 Gen1 Ports / 1 x RJ-45 LAN Port / 1 x Clear CMOS Button / 1 x BIOS Flashback Button / 1 x Line Out Jack (Gold Audio Jack) / 1 x Microphone Input Jack (Gold Audio Jack)*Supports USB PD 3.0 up to 9V@3A (27W) / 5V@3A (15W) charging** Device exceeds USB 3.2 Type-A power rating of 5V@0.9A (4.5W) may trigger over-current protection (OCP), will require system reboot to restore USB power.

Unique Feature

Superb Productivity / PCIe Gen5 (Graphics, M.2) / Blazing M.2 Gen5 Fan Heatsink / Dual Channel DDR5 / USB4 Type-C Ports (40 Gb/s)Rock-Solid Durability / Ultra Low-Loss PCB / 24+2+1 Power Phase, 105A SPS with Enlarged Heatsink Armor / Flexible Integrated I/O Shield / Nichicon 12K Black Caps (100% Japan made high quality conductive polymer capacitors)Ultrafast Gaming / Killer 2.5G LAN, Killer 802.11ax Wi-Fi 6E Module / Killer DoubleShot Pro / ASRock Lightning Gaming PortsEZ Update / BIOS Flashback Button / ASRock Auto Driver Installer

Software and UEFI

Software / ASRock Motherboard Utility (A-Tuning) / Killer Control Center / ASRock Polychrome SYNCUEFI / ASRock Full HD UEFI / ASRock Auto Driver Installer / ASRock Instant Flash
