Sockel

AM5

Chipset

AMD X600 / Pro600

M.2-platser

2

Ethernet

1 Gigabit

Max minne

96 GB

PCIe-platser

1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module

SATA-portar

2

Ljudkodek

Realtek ALC269

Dimensioner

170 × 170mm

Formfaktor

Mini-ITX

Minnestyp

DDR5

Displayutgångar

Integrated AMD RDNA graphics (Actual support may vary by CPU) / Four graphics output options: 2 x HDMI, 1 x DisplayPort 1.4, 1x LVDS / 2 x HDMI 2.1 TMDS 8G Compatible, supports HDR, HDCP 2.3 and max. resolution up to 4K 120HzHDMI x 1 port (Rear)*HDMI x 1 port (Internal) / 1 x DisplayPort 1.4 with DSC (compressed), supports HDCP 2.3 and max. resolution up to 4K 120Hz (Rear DP2)** / 1 x LVDS, supports max. resolution up to Full HD (1920x1080) 60Hz*Standard: HDMI; Optional: HDMI + DisplayPort(Rear DP1) (no Internal HDMI included)**Standard: DisplayPort(Rear DP2); Optional: D-Sub

Max minneshastighet

6400 MHz

Övriga specifikationer

OS

Microsoft Windows 10 64-bit / 11 64-bit

BIOS

256Mb AMI UEFI Legal BIOS with GUI support

Connector

* (Optional) 1 x Onboard TPM 2.0 (INFINEON SLB9672 or NUVOTON NPCT750AADYX) / 1 x Chassis Intrusion Header / 1 x Panel Voltage Selection Header / 1 x Backlight Inverter Voltage Selection Header / 1 x FPD Brightness Header / 1 x Panel Off Header / 1 x LVDS Connector / 1 x CPU Fan Connector (4-pin)* The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power. / 1 x 4 pin 19V Power Connector* (Optional) 1 x Chassis Fan Connector (4-pin) (Smart Fan Speed Control) / 1 x Front Panel Audio Connector / 1 x Internal Speaker Header (4-Pin) / 1 x Digital MIC Header / 2 x SATA Power Connectors / 1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD Protection) / 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) (Supports ESD Protection)

CPU Cooler

Supports CPU coolers with Intel LGA1700 (78mm x 78mm) mounting holes**Please note that a CPU cooler compatible with proprietary AMD socket backplate is required.

Accessories

I/O Shield (Optional) / 1 x SATA Data Cable (Optional) / 1 x SATA Power Cable (Optional) / 2 x Screws for M.2 Sockets / 1 x Screw for WiFi Module / 1 x Standoff for M.2 Socket

Certifications

FCC, CE / ErP/EuP ready (ErP/EuP ready power supply is required)

Rear Panel I/O

1 x DC Jack (Compatible with the 19V power adapter) / 1 x DisplayPort 1.4 (DP2)* / 1 x HDMI Port: HDMI2 (Internal) / 1 x HDMI Port: HDMI1 (Rear)** / 1 x USB 3.2 Gen2 Type-A Port / 1 x USB 3.2 Gen2 Type-C Port*** / 2 x USB 3.2 Gen1 Type-A Ports / 1 x RJ-45 LAN Port with LED / HD Audio Jacks: Line out / Microphone*Optional: 1 x D-Sub Port**Optional: 1 x DisplayPort 1.4 (DP1) + 1 x HDMI Port: HDMI1 (Rear) (no Internal HDMI included)***Optional: 1 x USB 3.2 Gen2 Type-A Ports

Unique Feature

ASRock Super Alloy / High Density Glass Fabric PCBASRock Full Spike Protection (for all USB, Audio, LAN Ports)

Hardware Monitor

CPU Temperature Sensing / CPU Fan Tachometer / CPU Quiet Fan (Auto adjust chassis fan speed by CPU temperature) / CPU Fan Multi-Speed Control / CASE OPEN detection / Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore
