Chipset

AMD X300

Ethernet

1 Gigabit

Max minne

64 GB

PCIe-platser

1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module

SATA-portar

1

Ljudkodek

Realtek ALC233

Dimensioner

170 × 170mm

Formfaktor

Mini-ITX

Minnestyp

DDR4

Displayutgångar

Integrated AMD Radeon Vega Series Graphics in Ryzen Series APU* / DirectX 12, Pixel Shader 5.0 / Shared memory default 2GB. Max Shared memory supports up to 16GB.** / Three graphics output options: 2 x HDMI, 1 x LVDS ports / Supports 2 x HDMI 2.1 with max. resolution up to 4K@ 60Hz / Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI 2.1 Port / Supports LVDS with max. resolution up to 1920x1080 @ 60Hz / Supports HDCP 2.3 with HDMI 2.1 Port****Actual support may vary by CPU**The Max shared memory 16GB requires 32GB system memory installed.***Picasso supports HDCP 2.2 with HDMI 2.0 Port

Övriga specifikationer

OS

Microsoft Windows 10 64-bit

BIOS

128Mb AMI UEFI Legal BIOS with GUI support / Supports "Plug and Play" / ACPI 5.1 compliance wake up events / Supports jumperfree / SMBIOS 2.3 support / DRAM Voltage adjustment

Connector

1 x Chassis Intrusion Header / 1 x Panel Voltage Selection Header / 1 x Backlight Inverter Voltage Selection Header / 1 x FPD Brightness Header / 1 x Panel Off Header / 1 x LVDS Connector / 2 x CPU Fan Connectors (4-pin)* / 1 x 4 pin 19V Power Connector / 1 x Front Panel Audio Connector / 1 x Internal Speaker Header (4-Pin) / 1 x SATA Power Connector / 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection)*The CPU Fan Connectors support the CPU fan of maximum 1A (12W) fan power.

Accessories

Quick Installation Guide (optional) / I/O Shield (optional) / 1 x SATA Data Cable (optional) / 1 x SATA Power Cable (optional) / 2 x Screws for M.2 Sockets

Certifications

FCC, CE / ErP/EuP ready (ErP/EuP ready power supply is required)

Rear Panel I/O

1 x DC Jack (Compatible with the 19V power adapter) / 1 x Serial Port: COM / 2 x HDMI Ports: HDMI1 (Rear), HDMI2 (Internal) / 3 x USB 3.2 Gen1 Type-A Ports (Supports ESD Protection) / 1 x USB 3.2 Gen1 Type-C (co-layout USB 3.2 Gen1 Type-A) Port (Supports ESD Protection) / 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) / HD Audio Jacks: Line out / Microphone

Unique Feature

ASRock Super Alloy / Matte Black PCB / High Density Glass Fabric PCBASRock Ultra M.2 (PCIe Gen3 x4 & SATA3)ASRock Full Spike Protection (for all USB, Audio, LAN Ports)

Hardware Monitor

CPU Temperature Sensing / CPU Fan Tachometer / CPU Quiet Fan (Auto adjust chassis fan speed by CPU temperature) / CPU Fan Multi-Speed Control / CASE OPEN detection / Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore
