Chipset

AMD X300

M.2-platser

2

Ethernet

1 Gigabit

Max minne

64 GB

PCIe-platser

1 x M.2 Socket (Key E), supports type 2230 WiFi/BT module

SATA-portar

2

Ljudkodek

Realtek ALC233

Dimensioner

140 × 147mm

Formfaktor

STX

Minnestyp

DDR4

Displayutgångar

Integrated AMD Radeon Vega Series Graphics in Ryzen Series APU* / DirectX 12, Pixel Shader 5.0 / Shared memory default 2GB. Max Shared memory supports up to 16GB.* / Three graphics output options: D-Sub, DisplayPort 1.2 and HDMI / Supports Triple Monitor / Supports HDMI with max. resolution up to 4K x 2K (4096x2160) @ 60Hz / Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz / Supports DisplayPort 1.2 with max. resolution up to 4K x 2K (4096x2304) @ 60Hz / Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI Port (Compliant HDMI monitor is required) / Supports HDCP with HDMI and DisplayPort 1.2 Ports / Supports 4K Ultra HD (UHD) playback with HDMI and DisplayPort 1.2 Ports*Actual support may vary by CPU**The Max shared memory 16GB requires 32GB system memory installed.

Övriga specifikationer

OS

Microsoft Windows 10 64-bit

BIOS

128Mb AMI UEFI Legal BIOS with GUI support / Supports "Plug and Play" / ACPI 5.1 compliance wake up events / Supports jumperfree / SMBIOS 2.3 support / DRAM Voltage adjustment

Connector

1 x Chassis Intrusion Header / 2 x CPU Fan Connectors (2 x 4-pin) / 1 x Front Panel Header / 1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD Protection) / 1 x Audio Header

Accessories

I/O Shield / 2 x SATA Data with Power Cable / 2 x Screws for M.2 Sockets / 1 x Screw for WiFi Module

Certifications

FCC, CE / ErP/EuP ready (ErP/EuP ready power supply is required)

Rear Panel I/O

1 x DC Jack (Compatible with the 19V power adapter)* / 1 x D-Sub Port / 1 x HDMI Port / 1 x DisplayPort 1.2 / 1 x USB 2.0 Port (Supports ESD Protection) / 1 x USB 3.1 Gen1 Port (Supports ESD Protection) / 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)*Please use 120W power adapter for 65W CPU and 90W power adapter for 35W CPU.

Unique Feature

Super Alloy / High Density Glass Fabric PCB / Sapphire Black PCB Ultra M.2 (PCIe Gen3 x4)Full Spike Protection (for all USB, Audio, LAN Ports)

Hardware Monitor

CPU Temperature Sensing / CPU Fan Tachometer / CPU Quiet Fan (Auto adjust chassis fan speed by CPU temperature) / CPU Fan Multi-Speed Control / CASE OPEN detection / Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore

Software and UEFI

Software / ASRock Motherboard Utility (A-Tuning) / ASRock Polychrome SYNC*UEFI / ASRock Full HD UEFI / ASRock Instant Flash*These utilities can be downloaded from ASRock Live Update & APP Shop.
