Sockel

LGA 2066

Chipset

Intel X299

M.2-platser

3

Ethernet

2.5 Gigabit

Max minne

256 GB

PCIe-platser

4 x PCI Express 3.0 x16 Slots* / 1 x PCI Express 3.0 x1 Slot / Supports AMD 3-Way CrossFireX and CrossFireX** / Supports NVIDIA 3-Way SLI and SLI** / 1 x Vertical M.2 Socket (Key E) with the bundled WiFi-802.11ax module (on the rear I/O) / 15μ Gold Contact in VGA PCIe Slot (PCIE1 and PCIE3)*If you install CPU with 48 lanes, PCIE1/PCIE2/PCIE3/PCIE5 will run at x16/x8/x16/x8. If a M.2 PCI Express module is installed on M2_1 or M2_2, PCIE2 will downgrade to x4 mode. If M.2 PCI Express modules are installed on M2_1 and M2_2, PCIE2 will be disabled.If you install CPU with 44 lanes, PCIE1/PCIE2/PCIE3/PCIE5 will run at x16/x4/x16/x8. If a M.2 PCI Express module is installed on M2_1, PCIE2 will be disabled.If you install CPU with 28 lanes, PCIE1/PCIE2/PCIE3/PCIE5 will run at x16/x4/x8/x0. If a M.2 PCI Express module is installed on M2_1, PCIE2 will be disabled.Supports NVMe SSD as boot disks**3-Way CrossFireX and 3-Way SLI are only supported with CPU with 48 lanes or 44 lanes.

SATA-portar

8

Ljudkodek

Realtek ALC1220

Dimensioner

305 × 244mm

Formfaktor

ATX

Minnestyp

DDR4

Minnesplatser

8

Displayutgångar

n/a

Övriga specifikationer

OS

Microsoft Windows 10 64-bit

BIOS

2 x 128Mb AMI UEFI Legal BIOS with multilingual GUI support (1 x Main BIOS and 1 x Backup BIOS) / Supports Secure Backup UEFI Technology / ACPI 6.1 Compliant wake up events / SMBIOS 3.0 Support / CPU, DRAM, VPPM, VTTM, PCH 1.0V, VCCMPHY, VCCIO, VCCSA, CPUPLL, CLK VDD Voltage Multi-adjustment

Connector

1 x Virtual RAID On CPU Header / 1 x SPI TPM Header / 1 x Power LED and Speaker Header / 2 x RGB LED Headers* / 2 x Addressable LED Headers** / 1 x CPU Fan Connector (4-pin)*** / 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)**** / 5 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)***** / 1 x 24 pin ATX Power Connector (Hi-Density Power Connector) / 2 x 8 pin 12V Power Connectors (Hi-Density Power Connector) / 1 x Front Panel Audio Connector (15μ Gold Audio Connector) / 1 x Thunderbolt AIC Connector (5-pin)****** / 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection) / 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) (Supports ESD Protection) / 1 x Front Panel Type C USB 3.2 Gen2 Header (ASMedia ASM3142) / 1 x Dr. Debug with LED / 1 x Power Button with LED / 1 x Reset Button*Supports in total up to 12V/3A, 36W LED Strip**Support in total up to 5V/3A, 15W LED Strip***The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power.****The CPU/Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power.*****The Chassis/Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power.CPU_FAN2/WP, CHA_FAN1~5/WP can auto detect if 3-pin or 4-pin fan is in use.******The Thunderbolt AIC card can be installed in the enabled PCIe slot (depending on CPU type).

Accessories

4 x SATA Data Cables / 1 x ASRock SLI_HB_Bridge_2S Card / 1 x ASRock WiFi 2.4/5 GHz Antenna / 1 x ASRock Screwdriver / 3 x Screws for M.2 Sockets / 3 x Standoffs for M.2 Sockets

Certifications

FCC, CE / ErP/EuP ready (ErP/EuP ready power supply is required)

Rear Panel I/O

2 x Antenna Ports / 1 x Optical SPDIF Out Port / 2 x USB 2.0 Ports (Supports ESD Protection) / 1 x USB 3.2 Gen2x2 Type-C Port (20 Gb/s) (ASMedia ASM3242) (Supports ESD Protection) / 4 x USB 3.2 Gen1 Ports (Supports ESD Protection) / 2 x RJ-45 LAN Ports with LED (ACT/LINK LED and SPEED LED) / 1 x Clear CMOS Button / HD Audio Jacks: Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone (Gold Audio Jacks)*Ultra USB Power is supported on USB3_3_4 ports.ACPI wake-up function is not supported on USB3_3_4 ports.

Unique Feature

ASRock USB 3.2 Gen2 / ASRock Front Panel Type C USB 3.2 Gen2 Header (10 Gb/s) / ASRock Type C USB 3.2 Gen2x2 Port (20 Gb/s)ASRock Super Alloy / XXL Aluminum Alloy Heatsink / Premium 60A Power Choke / Dr. MOS / Nichicon 12K Black Caps (100% Japan made high quality conductive polymer capacitors) / Matte Black PCB / High Density Glass Fabric PCB / 8 Layer PCB / 2oz Copper PCB2.5G LANIntel 802.11ax WiFiASRock Steel SlotsASRock Full Coverage M.2 HeatsinkASRock Ultra M.2 (PCIe Gen3 x4 & SATA3)ASRock Ultra USB PowerASRock Full Spike Protection (for all USB, Audio, LAN Ports)ASRock Live Update & APP Shop

Hardware Monitor

Temperature Sensing: CPU, CPU/Water Pump, Chassis/Water Pump Fans / Fan Tachometer: CPU, CPU/Water Pump, Chassis/Water Pump Fans / Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, CPU/Water Pump, Chassis/Water Pump Fans / Fan Multi-Speed Control: CPU, CPU/Water Pump, Chassis/Water Pump Fans / Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM, PCH 1.0V, VCCIO, VCCSA

Software and UEFI

Software / Dragon 2.5G LAN Software / ASRock Motherboard Utility (A-Tuning) / ASRock Polychrome SYNC*UEFI / ASRock EZ Mode / ASRock Full HD UEFI / ASRock My Favorites in UEFI / ASRock Instant Flash / ASRock Internet Flash / ASRock Easy RAID Installer*These utilities can be downloaded from ASRock Live Update & APP Shop.
