Sockel

sTR5

Chipset

AMD WRX90

M.2-platser

2

Ethernet

10 Gigabit

PCIe-platser

CPU: / 7 x PCIe 5.0 x16 Slots (PCIE1/PCIE2/PCIE3/PCIE4/PCIE5/PCIE7 at x16; PCIE6 at x8)* / 15μ Gold Contact in VGA PCIe Slots*Supports NVMe SSD as boot disks

SATA-portar

4

Ljudkodek

Realtek ALC1220

Dimensioner

305 × 330mm

Formfaktor

EEB

Minnestyp

DDR5

Minnesplatser

8

Displayutgångar

Aspeed AST2600 BMC Controller / 1 x DisplayPort 1.1a with max. resolution up to 1920x1200 @ 60Hz**DisplayPort 1.1a does not support audio function.

Max minneshastighet

7600 MHz

Övriga specifikationer

OS

Microsoft Windows 11 64-bit

USB

CPU: / 2 x USB4 Type-C (Rear) / 4 x USB 3.2 Gen2 Type-A (Rear)Chipset: / 1 x USB 3.2 Gen2x2 Type-C (Front) / 4 x USB 3.2 Gen1 Type-A (2 Rear, 2 Front) / 4 x USB 2.0 (Front)*All USB ports support ESD Protection

BIOS

256Mb AMI UEFI Legal BIOS with GUI support

RAID

Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices / Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe storage devices**Requires additional M.2 NVMe expansion cards to support RAID 10

Connector

2 x Thermistor Cable Headers / 1 x Front VGA Header / 1 x COM Port Header / 1 x Power LED and Speaker Header / 1 x Intelligent Platform Management Bus Header / 1 x PSU SMBus Header / 1 x BMC SMBus Header / 1 x Auxiliary Panel Header / 2 x Addressable LED Headers* / 1 x CPU Fan Connector (4-pin)** / 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)*** / 3 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)**** / 1 x 24 pin ATX Power Connector (Hi-Density Power Connector) / 1 x 3 pin ATX Power Connector***** / 2 x 8 pin ATX 12V Power Connectors (Hi-Density Power Connector) (for Motherboard)****** / 2 x 6 pin PCIe 12V Power Connectors (Hi-Density Power Connector) (for Motherboard)****** / 2 x 6 pin Graphics 12V Power Connectors (Hi-Density Power Connector) (for PCIe card)******* / 1 x Right Angle Front Panel Audio Connector / 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) / 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) / 1 x Front Panel Type C USB 3.2 Gen2x2 Header (20 Gb/s) / 2 x SGPIO Headers / 1 x CPU HP-SMBus Connector / 1 x Non Maskable Interrupt Button Header / 1 x Dr. Debug with LED / 1 x Power Button with LED / 1 x Reset Button with LED / 1 x Clear CMOS Button*Support in total up to 5V/3A, 15W LED Strip**CPU_FAN1 supports the fan power up to 1A (12W).***CPU_FAN2/WP supports the fan power up to 2A (24W).****CHA_FAN1~3/WP support the fan power up to 2A (24W).*****Plug the Multi PSU Adaptor Cable that comes with the package to ATX_CON1 if you use a secondary PSU.******It is required to connect both ATX12V1 and ATX12V2; otherwise, the system may not boot up properly.It is required to connect all 8 pin and 6 pin 12V Power Connectors when overclocking.*******It is required to connect 6 pin PCIE 12V Power Cables to either GFX_12V1 or GFX_12V2; otherwise, the system may not boot up properly.

Accessories

1 x User Manual / 1 x I/O Shield / 4 x SATA Data Cables / 2 x Thermistor Cables / 1 x Multi PSU Adaptor Cable / 2 x Screws for M.2 Sockets / 2 x Standoffs for M.2 Sockets

Certifications

FCC, CE / ErP/EuP ready (ErP/EuP ready power supply is required) / CEC Tier II ready

Rear Panel I/O

1 x DisplayPort 1.1a / 1 x Optical SPDIF Out Port / 2 x USB4 Type-C Ports (40 Gb/s)* / 4 x USB 3.2 Gen2 Type-A Ports (10 Gb/s) / 2 x USB 3.2 Gen1 Type-A Ports / 2 x RJ-45 LAN Ports / 1 x RJ45 Dedicated IPMI LAN Port / 1 x Line Out Jack (Gold Audio Jack) / 1 x Microphone Input Jack (Gold Audio Jack)*USB_TC1 supports USB PD 3.0 up to 9V@3A (27W) / 5V@3A (15W) charging; USB_TC2 supports USB PD 3.0 up to 5V@3A (15W) charging.

Unique Feature

Superb Productivity / PCIe Gen5 (Graphics, M.2) / Eight Channel DDR5 / USB4 Type-C Ports (40 Gb/s)Rock-Solid Durability / Ultra Low-Loss PCB / 18+3+3 Power Phase, 110A SPS for VCore / 20K Long-lasting Black Caps (high quality and conductive polymer capacitors) Ultrafast Connectivity / Dual Intel 10G LANEZ Update / ASRock Auto Driver Installer

Software and UEFI

Software / ASRock Polychrome SYNC*UEFI / ASRock Full HD UEFI / ASRock Auto Driver Installer / ASRock Instant Flash*These utilities can be downloaded from ASRock Live Update & APP Shop.
