WiFi

WiFi 6

Sockel

sWRX8

Chipset

AMD WRX80

M.2-platser

2

Ethernet

10 Gigabit

Max minne

2048 GB

PCIe-platser

CPU: / 7 x PCIe 4.0 x16 Slots (PCIE1/PCIE2/PCIE3/PCIE5/PCIE7 at x16; PCIE4/PCIE6 at x8)*Chipset: / 1 x Vertical M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module / 15μ Gold Contact in VGA PCIe Slots (PCIE1, PCIE2,PCIE3, PCIE5 and PCIE7)*Supports NVMe SSD as boot disks

SATA-portar

8

Ljudkodek

Realtek ALC4050H

Dimensioner

305 × 272mm

Formfaktor

EATX

Minnestyp

DDR4

Minnesplatser

8

Displayutgångar

Aspeed AST2500 BMC Controller / Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz

Max minneshastighet

4400 MHz

Övriga specifikationer

OS

Microsoft Windows 10 64-bit / 11 64-bit*Sleep (S3) mode is not supported on this motherboard.

BIOS

256Mb AMI UEFI Legal BIOS with GUI support / Supports "Plug and Play" / ACPI 5.1 compliance wake up events / Supports jumperfree / SMBIOS 2.3 support / CPU, CPU VDDCR_SOC, DRAM, VPPM, PREM VDD_CLDO, PERM VDDCR_SOC, +1.8V, VDDP Voltage Multi-adjustment

RAID

Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices / Supports RAID 0, RAID 1 and RAID 5 for M.2 NVMe storage devices**Requires additional M.2 NVMe expansion cards to support RAID 5

Connector

1 x SPI TPM Header / 1 x COM Port Header / 1 x Intelligent Platform Management Bus Header / 1 x PSU SMBus Header / 1 x BMC SMBus Header / 1 x Auxiliary Panel Header / 1 x Power LED and Speaker Header / 1 x RGB LED Header* / 2 x Addressable LED Headers** / 1 x CPU Fan Connector (4-pin)*** / 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)**** / 3 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)***** / 1 x 24 pin ATX Power Connector (Hi-Density Power Connector)****** / 2 x 8 pin 12V Power Connectors (Hi-Density Power Connector) / 1 x 6 pin 12V Power Connector (Hi-Density Power Connector) / 1 x Front Panel Audio Connector (15μ Gold Audio Connector) / 1 x Right Angle Front Panel Audio Connector******* / 1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD Protection) / 2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports) (Supports ESD Protection) / 1 x Front Panel Type C USB 3.2 Gen2 Header (Supports ESD Protection) / 1 x Non Maskable Interrupt Button Header / 1 x Dr. Debug with LED / 1 x Power Button with LED / 1 x Reset Button*Supports in total up to 12V/3A, 36W LED Strip**Support in total up to 5V/3A, 15W LED Strip***The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power.****The CPU/Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power.*****The Chassis/Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power.CPU_FAN2/WP, CHA_FAN1/WP, CHA_FAN2/WP and CHA_FAN3/WP can auto detect if 3-pin or 4-pin fan is in use.******We recommend using a PSU with a max. current of 3A on +5VSB.*******Connect the audio device to either one of the audio connectors.

Accessories

Quick Installation Guide / 4 x SATA Data Cables / 1 x ASRock WiFi 2.4/5/6 GHz Antenna / 2 x Screws for M.2 Sockets / 2 x Standoffs for M.2 Sockets

Certifications

FCC, CE / ErP/EuP ready (ErP/EuP ready power supply is required) / CEC Tier II ready

Rear Panel I/O

2 x Antenna Ports / 1 x D-Sub Port / 1 x Optical SPDIF Out Port / 2 x USB 4.0 Thunderbolt 4 Type-C Ports (40 Gb/s for USB 4.0 protocol; 40Gb/s for Thunderbolt protocol) (Supports ESD Protection)* / 2 x Mini DisplayPort Input Ports(For Thunderbolt)** / 4 x USB 3.2 Gen2 Ports (10 Gb/s) (Supports ESD Protection)*** / 2 x USB 3.2 Gen1 Ports (Supports ESD Protection) / 2 x RJ-45 LAN Ports with LED (ACT/LINK LED and SPEED LED) / 1 x RJ45 Dedicated IPMI LAN Port with LED (ACT/LINK LED and SPEED LED) / 1 x Clear CMOS Button / HD Audio Jacks: Rear Speaker / Central / Line in / Front Speaker / Microphone (Gold Audio Jacks)*Supports USB-PD 3.0 9V/3A(27W) and 5V/3A(15W). USB-C monitors not supported.** Please choose regular mini DisplayPort to DisplayPort adapter Cables instead of right angled ones if you use two mini DisplayPort input ports simultaneously.***Ultra USB Power is supported on USB31_1_2 ports.ACPI wake-up function is not supported on USB31_1_2 ports.

Unique Feature

ASRock USB 3.2 Gen2 / ASRock Front Panel Type C USB 3.2 Gen2 Header (10 Gb/s) / ASRock USB 3.2 Gen2 Type-A Port (10 Gb/s)ASRock Super Alloy / XXL Aluminum Alloy Heatsink / Premium Power Choke / 105A Dr.MOS / Nichicon 12K Black Caps (100% Japan made high quality conductive polymer capacitors) / Matte Black PCB / High Density Glass Fabric PCB / 14 Layer PCB / 2oz Copper PCBServer-Grade Low-Loss PCBDual Marvell (Aquantia) 10GbE LAN802.11ax Wi-Fi 6EASRock Auto Driver InstallerASRock Steel SlotASRock Full Coverage M.2 HeatsinkASRock Hyper M.2 (PCIe Gen4x4)ASRock Ultra USB PowerASRock Full Spike Protection (for all USB, Audio, LAN Ports)ASRock Live Update & APP Shop

Hardware Monitor

Fan Tachometer: CPU, CPU/Water Pump, Chassis/Water Pump Fans / Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, CPU/Water Pump, Chassis/Water Pump Fans / Fan Multi-Speed Control: CPU, CPU/Water Pump, Chassis/Water Pump Fans / Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, CPU VDDCR_SOC, DRAM, PREM VDDCR_SOC, +1.8V

Software and UEFI

Software / ASRock Motherboard Utility (A-Tuning) / ASRock Polychrome SYNC*UEFI / ASRock Full HD UEFI / ASRock Instant Flash*These utilities can be downloaded from ASRock Live Update & APP Shop.
