WiFi

WiFi 6

Sockel

LGA 4677

Chipset

Intel W790 / Supports Intel vPro Technology / Supports Intel Active Management Technology

M.2-platser

4

Ethernet

10 Gigabit

PCIe-platser

CPU: / 4 x PCIe 5.0 x16 Slots (PCIE1/PCIE3 at x16; PCIE2/PCIE5 at x8)*Chipset: / 1 x PCIe 4.0 x16 Slot (PCIE4), supports x4 mode* / 1 x Vertical M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module / 15μ Gold Contact in VGA PCIe Slots*Supports NVMe SSD as boot disks

SATA-portar

8

Ljudkodek

Realtek ALC897

Dimensioner

305 × 277mm

Formfaktor

EATX

Minnestyp

DDR5

Minnesplatser

8

Displayutgångar

n/a

Max minneshastighet

6800 MHz

Övriga specifikationer

OS

Microsoft Windows 10 64-bit / 11 64-bit / Linux**Linux supported by Intel via the upstreaming of Intel Linux drivers to the Linux Open Source Community. Adoption into individual Linux distributions is dependent upon the OS vendor

USB

2 x Thunderbolt 4 Type-C (Rear) / 1 x USB 3.2 Gen2x2 Type-C (Front) / 2 x USB 3.2 Gen2 Type-A (Rear) / 8 x USB 3.2 Gen1 (4 Rear, 4 Front) / 3 x USB 2.0 (Front)* All USB ports support ESD Protection

BIOS

256Mb AMI UEFI Legal BIOS with GUI support

RAID

Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices / Supports RAID 0, RAID 1, RAID 5 and RAID 10 for M.2 NVMe storage devices

Connector

1 x Virtual RAID On CPU Header / 1 x SPI TPM Header / 1 x Chassis Intrusion and Speaker Header / 1 x CPU Fan Connector (4-pin)* / 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)** / 3 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)*** / 1 x 24 pin ATX Power Connector (Hi-Density Power Connector) / 2 x 8 pin 12V Power Connectors (Hi-Density Power Connector) (for Motherboard) / 1 x 6 pin 12V Power Connector (Hi-Density Power Connector) (for Motherboard)**** / 2 x 8 pin 12V Power Connectors (Hi-Density Power Connector) (for PCIe card)***** / 1 x Front Panel Audio Connector / 2 x USB 2.0 Headers (Support 3 USB 2.0 ports) / 2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports) / 1 x Front Panel Type C USB 3.2 Gen2x2 Header (20 Gb/s) / 1 x Clear CMOS Button / 1 x Dr. Debug with LED / 1 x Power Button with LED / 1 x Reset Button with LED*CPU_FAN1 supports the fan power up to 1A (12W).**CPU_FAN2/WP_3A supports the fan power up to 3A (36W).***CHA_FAN1~3/WP support the fan power up to 2A (24W).CPU_FAN2/WP_3A and CHA_FAN1~3/WP can auto detect if 3-pin or 4-pin fan is in use.****It is optional to connect an ATX 12V 6-pin Cable to ATX12V3, which provides more power for overclocking.*****Use either GTX_12V1 or GTX_12V2 when you install one or two PCIe card(s). Use both connectors when you install more than two PCIe cards. Otherwise, the system may not boot up properly.

Accessories

1 x User Manual / 4 x SATA Data Cables / 1 x ASRock WiFi 2.4/5/6 GHz Antenna / 1 x CPU Carrier for LGA 4677 E1A / 1 x CPU Carrier for LGA 4677 E1B / 4 x Screws for M.2 Sockets / 2 x Standoffs for M.2 Sockets

Certifications

FCC, CE / ErP/EuP ready (ErP/EuP ready power supply is required) / CEC Tier II ready

Rear Panel I/O

2 x Antenna Ports / 1 x Optical SPDIF Out Port / 2 x Thunderbolt 4 Type-C Ports* / 2 x USB 3.2 Gen2 Type-A Ports (10 Gb/s) / 4 x USB 3.2 Gen1 Ports / 3 x RJ-45 LAN Ports / 1 x BIOS Flashback Button / 1 x Line Out Jack (Gold Audio Jack) / 1 x Microphone Input Jack (Gold Audio Jack)*Supports USB PD 3.0 up to 9V@3A (27W) / 5V@3A (15W) charging

Unique Feature

Superb Productivity / PCIe Gen5 (Graphics, M.2) / Quad Channel DDR5 / 2 Thunderbolt 4 Type-CRock-Solid Durability / Ultra Low-Loss PCB / 20+2 Power Phase, 90A SPS with Enlarged Heatsink Armor / Flexible Integrated I/O Shield / Nichicon 12K Black Caps (100% Japan made high quality conductive polymer capacitors)Ultrafast Connectivity / Dual Marvell (Aquantia) 10GbE LAN / Intel 2.5GbE LAN / Intel vPro for Workstations with Intel Advanced Management Technology / 802.11ax Wi-Fi 6EModule EZ Update / BIOS Flashback Button / ASRock Auto Driver Installer

Software and UEFI

Software / ASRock Motherboard Utility (A-Tuning)UEFI / ASRock My Favorites in UEFI / ASRock Auto Driver Installer / ASRock Instant Flash / ASRock Easy RAID Installer*These utilities can be downloaded from ASRock Live Update & APP Shop.
