WiFi

WiFi 6

Sockel

sTR5

Chipset

AMD TRX50

M.2-platser

2

Ethernet

10 Gigabit

PCIe-platser

CPU: / 3 x PCIe 5.0 x16 Slots (PCIE1/PCIE3 at x16; PCIE4 at x8)* / 1 x PCIe 4.0 x16 Slot (PCIE2), supports x4 mode* / 1 x PCIe 4.0 x16 Slot (PCIE5), supports x8 mode*Chipset: / 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module / 15μ Gold Contact in VGA PCIe Slots* Supports NVMe SSD as boot disks

SATA-portar

4

Ljudkodek

Realtek ALC1220

Dimensioner

305 × 277mm

Formfaktor

EATX

Minnestyp

DDR5

Minnesplatser

4

Displayutgångar

n/a

Max minneshastighet

7600 MHz

Övriga specifikationer

OS

Microsoft Windows 11 64-bit

USB

CPU: / 1 x USB 3.2 Gen2x2 Type-C (Rear) / 4 x USB 3.2 Gen2 Type-A (Rear)Chipset: / 2 x USB 3.2 Gen2 Type-C (1 Rear, 1 Front) / 4 x USB 3.2 Gen1 Type-A (2 Rear, 2 Front) / 4 x USB 2.0 (Front)* All USB ports support ESD Protection

BIOS

256Mb AMI UEFI Legal BIOS with GUI support

RAID

Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices / Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe storage devices** Requires additional M.2 NVMe expansion cards to support RAID 10

Connector

2 x Thermistor Cable Headers / 1 x SPI TPM Header / 1 x COM Port Header / 1 x Chassis Intrusion and Speaker Header / 2 x Addressable LED Headers* / 1 x CPU Fan Connector (4-pin)** / 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)*** / 3 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)**** / 1 x 24 pin ATX Power Connector (Hi-Density Power Connector) / 1 x 3 pin ATX Power Connector***** / 2 x 8 pin ATX 12V Power Connectors (Hi-Density Power Connector) (for Motherboard)****** / 2 x 6 pin PCIe 12V Power Connectors (Hi-Density Power Connector) (for Motherboard)****** / 1 x 6 pin Graphics 12V Power Connector (Hi-Density Power Connector) (for PCIe card)******* / 1 x Front Panel Audio Connector (15μ Gold Audio Connector) / 1 x Thunderbolt AIC Connector (5-pin) (Supports ASRock Thunderbolt 4 AIC Card) / 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) / 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) / 1 x Front Panel Type C USB 3.2 Gen2 Header (10 Gb/s) / 1 x Dr. Debug with LED / 1 x Power Button with LED / 1 x Reset Button with LED* Support in total up to 5V/3A, 15W LED Strip** CPU_FAN1 supports the fan power up to 1A (12W).*** CPU_FAN2/WP supports the fan power up to 2A (24W).**** CHA_FAN1~3/WP support the fan power up to 2A (24W).***** Plug the Multi PSU Adaptor Cable that comes with the package to ATX_CON1 if you use a secondary PSU.****** It is required to connect both ATX12V1 and ATX12V2; otherwise, the system may not boot up properly.****** It is required to connect all 8 pin and 6 pin 12V Power Connectors when overclocking.******* It is required to connect a 6 pin PCIE 12V Power Cable to GFX_12V1; otherwise, the system may not boot up properly.

Accessories

1 x User Manual / 4 x SATA Data Cables / 1 x ASRock WiFi 2.4/5/6 GHz Antenna / 2 x Thermistor Cables / 1 x Multi PSU Adaptor Cable / 2 x Screws for M.2 Sockets / 2 x Standoffs for M.2 Sockets

Certifications

FCC, CE / ErP/EuP ready (ErP/EuP ready power supply is required)

Rear Panel I/O

2 x Antenna Ports / 1 x Optical SPDIF Out Port / 1 x USB 3.2 Gen2x2 Type-C Port (20 Gb/s) / 4 x USB 3.2 Gen2 Type-A Ports (10 Gb/s) / 1 x USB 3.2 Gen2 Type-C Port (10 Gb/s) / 2 x USB 3.2 Gen1 Type-A Ports / 2 x RJ-45 LAN Ports / 1 x Clear CMOS Button / 1 x BIOS Flashback Button / 1 x Line Out Jack (Gold Audio Jack) / 1 x Microphone Input Jack (Gold Audio Jack)

Unique Feature

Superb Productivity / PCIe Gen5 (Graphics, M.2) / Quad Channel DDR5Rock-Solid Durability / Ultra Low-Loss PCB / 18+3+3 Power Phase, 110A SPS for VCore / Pre-Installed I/O Shield / 20K Long-lasting Black Caps (high quality and conductive polymer capacitors)Ultrafast Connectivity / 10G LAN, 2.5G LAN, 802.11ax Wi-Fi 6E ModuleEZ Update / BIOS Flashback Button / ASRock Auto Driver Installer

Software and UEFI

Software / ASRock Motherboard Utility (A-Tuning) / ASRock Dragon 2.5G LAN Software / ASRock Polychrome SYNC*UEFI / ASRock Full HD UEFI / ASRock Auto Driver Installer / ASRock Instant Flash*These utilities can be downloaded from ASRock Live Update & APP Shop.
